EPIC® H-A 10 SDR-LB
- Volume Discount
The robust metal housing for rectangular connectors has a single lever and a cable entry and can be used in control systems.These connectors are attractive because of their compact housing.Metal lid with sturdy hingeProtection rating UL50E tested
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Loading...
Basic information
| Degree of protection (IP), mounted | IP65 | Height | 57 | Length | 63 |
|---|---|---|---|---|---|
| Width | 29,5 | Operation temperature | 125 | Inflammability class of insulation material acc. with UL94 | HB |
| Housing coating | With powder coating | Locking mechanism | Single locking lever | Position cable feed | Sideways |
| Position of the shackle | Base unit | Material housing | Aluminium | Type of housing | Socket case |
| Corrosion resistant | True | EMC-version | False | UV resistant | True |
| With cable screw gland | False | With hinged lid | True | With interlocking device | True |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
