EPIC® H-B 16 TG 2X
- Volume Discount
The universal robust low housing consists of pivots for a single lever and 2 direct cable entries and is suitable for investment construction.Housing design H-B. The industry standard.Non-slip ridges for comfortable disconnectingFor easy introduction of two cablesProtection rating UL50E tested
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
19080500
Basic information
| Degree of protection (IP), mounted | IP65 | Height | 61 | Length | 93,3 |
|---|---|---|---|---|---|
| Width | 43 | Operation temperature | 125 | Inflammability class of insulation material acc. with UL94 | HB |
| Housing coating | With powder coating | Locking mechanism | Double locking levers | Position cable feed | Above |
| Position of the shackle | Base unit | Material housing | Aluminium | Type of housing | Plug case |
| Corrosion resistant | True | EMC-version | False | UV resistant | True |
| With cable screw gland | False | With hinged lid | False | With interlocking device | True |
This page is EPIC® H-B 16 TG 2X, part number 19080500.
You can find the detail information about specifications and dimensions on part number 19080500.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
