ÖLFLEX® CLASSIC FD 810 P
- Volume Discount
· Durable cable chain use with medium travel distances or increased acceleration (LAPP performance class “Core Line”)
· Resistant product thanks to the outer sheath material which is resistant to abrasion, notches and cuts
· Highly flexible cable design means excellent product performance
· Shorter core stranding allows very small bending radii
Application
· The PUR outer sheath is resistant to mineral oil-based lubricants and highly resistant to chemicals
· The cable design allows flexible, continuously flexing use in moving machine parts and in the cable chain
· The PUR outer sheath withstands high mechanical loads
· For use in control, regulating and measurement circuits
· Can be used in dry, wet and especially in harsh and oily environments
· Suitable for outdoor use, subject to the temperature range
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Length (m) | Nominal cross section conductor (mm2) | Number of cores (Core) | Outer diameter approx. (mm) | Protective conductor | |
|---|---|---|---|---|---|---|---|---|---|---|---|
217.90 € | 1 | Available | 8 Days | 10 | 100 | 0.5 | 2 | 5.3 | False | ||
2,179.02 € | 1 | Available | 46 Days | 10 | 1000 | 0.5 | 2 | 5.3 | False | ||
1,089.52 € | 1 | Available | 5 Days | 10 | 500 | 0.5 | 2 | 5.3 | False | ||
236.43 € | 1 | Available | 5 Days | 10 | 100 | 0.5 | 3 | 5.7 | True | ||
2,364.37 € | 1 | Available | 60 Days | 10 | 1000 | 0.5 | 3 | 5.7 | True | ||
1,182.18 € | 1 | Available | 5 Days | 10 | 500 | 0.5 | 3 | 5.7 | True | ||
261.98 € | 1 | Available | 5 Days | 10 | 100 | 0.5 | 4 | 6.3 | True | ||
2,619.88 € | 1 | Available | 69 Days | 10 | 1000 | 0.5 | 4 | 6.3 | True | ||
1,309.93 € | 1 | Available | 5 Days | 10 | 500 | 0.5 | 4 | 6.3 | True | ||
345.56 € | 1 | Available | 5 Days | 10 | 100 | 0.5 | 5 | 6.8 | True | ||
3,455.72 € | 1 | Available | 5 Days | 10 | 1000 | 0.5 | 5 | 6.8 | True | ||
1,727.87 € | 1 | Available | 8 Days | 10 | 500 | 0.5 | 5 | 6.8 | True | ||
441.03 € | 1 | Available | 5 Days | 10 | 100 | 0.5 | 7 | 8 | True | ||
4,410.42 € | 1 | Available | 5 Days | 10 | 1000 | 0.5 | 7 | 8 | True | ||
2,205.20 € | 1 | Available | 5 Days | 10 | 500 | 0.5 | 7 | 8 | True | ||
676.53 € | 1 | Available | 5 Days | 10 | 100 | 0.5 | 12 | 9.5 | True | ||
6,765.30 € | 1 | Available | 5 Days | 10 | 1000 | 0.5 | 12 | 9.5 | True | ||
3,382.64 € | 1 | Available | 5 Days | 10 | 500 | 0.5 | 12 | 9.5 | True | ||
449.09 € | 1 | Available | 46 Days | 10 | 50 | 0.5 | 18 | 11.4 | True | ||
898.17 € | 1 | Available | 5 Days | 10 | 100 | 0.5 | 18 | 11.4 | True | ||
8,981.70 € | 1 | Available | 82 Days | 10 | 1000 | 0.5 | 18 | 11.4 | True | ||
4,490.85 € | 1 | Available | 5 Days | 10 | 500 | 0.5 | 18 | 11.4 | True | ||
228.43 € | 1 | Available | 8 Days | 10 | 100 | 0.75 | 2 | 5.7 | False | ||
2,284.37 € | 1 | Available | 46 Days | 10 | 1000 | 0.75 | 2 | 5.7 | False | ||
1,142.18 € | 1 | Available | 5 Days | 10 | 500 | 0.75 | 2 | 5.7 | False | ||
250.27 € | 1 | Available | 46 Days | 10 | 100 | 0.75 | 3 | 6.2 | True | ||
2,502.72 € | 1 | Available | 8 Days | 10 | 1000 | 0.75 | 3 | 6.2 | True | ||
1,251.37 € | 1 | Available | 5 Days | 10 | 500 | 0.75 | 3 | 6.2 | True | ||
284.65 € | 1 | Available | 5 Days | 10 | 100 | 0.75 | 4 | 6.8 | True | ||
2,846.56 € | 1 | Available | 46 Days | 10 | 1000 | 0.75 | 4 | 6.8 | True | ||
1,423.29 € | 1 | Available | 5 Days | 10 | 500 | 0.75 | 4 | 6.8 | True | ||
347.37 € | 1 | Available | 46 Days | 10 | 100 | 0.75 | 5 | 7.4 | True | ||
3,473.59 € | 1 | Available | 46 Days | 10 | 1000 | 0.75 | 5 | 7.4 | True | ||
1,736.80 € | 1 | Available | 5 Days | 10 | 500 | 0.75 | 5 | 7.4 | True | ||
504.60 € | 1 | Available | 8 Days | 10 | 100 | 0.75 | 7 | 8.9 | True | ||
5,045.96 € | 1 | Available | 8 Days | 10 | 1000 | 0.75 | 7 | 8.9 | True | ||
2,522.99 € | 1 | Available | 5 Days | 10 | 500 | 0.75 | 7 | 8.9 | True | ||
383.75 € | 1 | Available | 46 Days | 10 | 50 | 0.75 | 12 | 10.6 | True | ||
767.48 € | 1 | Available | 8 Days | 10 | 100 | 0.75 | 12 | 10.6 | True | ||
7,674.87 € | 1 | Available | 8 Days | 10 | 1000 | 0.75 | 12 | 10.6 | True | ||
3,837.43 € | 1 | Available | 8 Days | 10 | 500 | 0.75 | 12 | 10.6 | True | ||
451.59 € | 1 | Available | 5 Days | 10 | 50 | 0.75 | 18 | 12.7 | True | ||
903.17 € | 1 | Available | 46 Days | 10 | 100 | 0.75 | 18 | 12.7 | True | ||
9,031.64 € | 1 | Available | 46 Days | 10 | 1000 | 0.75 | 18 | 12.7 | True | ||
4,515.82 € | 1 | Available | 5 Days | 10 | 500 | 0.75 | 18 | 12.7 | True | ||
617.83 € | 1 | Available | 5 Days | 10 | 50 | 0.75 | 25 | 15.2 | True | ||
12,356.75 € | 1 | Available | 46 Days | 10 | 1000 | 0.75 | 25 | 15.2 | True | ||
6,178.39 € | 1 | Available | 5 Days | 10 | 500 | 0.75 | 25 | 15.2 | True | ||
248.18 € | 1 | Available | 8 Days | 10 | 100 | 1 | 2 | 6.1 | False | ||
2,481.89 € | 1 | Available | 8 Days | 10 | 1000 | 1 | 2 | 6.1 | False | ||
1,240.93 € | 1 | Available | 5 Days | 10 | 500 | 1 | 2 | 6.1 | False | ||
281.00 € | 1 | Available | 8 Days | 10 | 100 | 1 | 3 | 6.6 | True | ||
2,810.06 € | 1 | Available | 5 Days | 10 | 1000 | 1 | 3 | 6.6 | True | ||
1,405.04 € | 1 | Available | 5 Days | 10 | 500 | 1 | 3 | 6.6 | True | ||
323.24 € | 1 | Available | 5 Days | 10 | 100 | 1 | 4 | 7.3 | True | ||
3,232.25 € | 1 | Available | 5 Days | 10 | 1000 | 1 | 4 | 7.3 | True | ||
1,616.13 € | 1 | Available | 5 Days | 10 | 500 | 1 | 4 | 7.3 | True | ||
375.63 € | 1 | Available | 5 Days | 10 | 100 | 1 | 5 | 8 | True | ||
3,756.29 € | 1 | Available | 5 Days | 10 | 1000 | 1 | 5 | 8 | True | ||
1,878.14 € | 1 | Available | 5 Days | 10 | 500 | 1 | 5 | 8 | True |
Loading...
Basic information
| Colour outer sheath | Grey | Material outer sheath | PUR (Polyurethane) | Nominal voltage U | 500 |
|---|---|---|---|---|---|
| Operating temperature, fix | 80 | Operating temperature, flexible | 70 | Conductor category | Class 6 = very flexible |
| Core identification | Numbers | Core insulation | PVC | Flame retardant | In accordance with EN 60332-1-2 |
| Halogen free (acc. EN 50267-2-2) | False | Low smoke (acc. EN 61034-2) | False | Low temperature resistant (acc. EN 60811-1-4) | False |
| Oil resistant (acc. EN 60811-2-1) | True | Screen over stranding | None | Screen over stranding element | None |
| Stranding element | No |
Configure
Basic Attributes
-
Length(m)
-
Nominal cross section conductor(mm2)
-
Number of cores(Core)
-
Outer diameter approx.(mm)
-
Protective conductor
- False
- True
Filter by standard shipping days
-
- All
- 5 Days or Less
- 8 Days or Less
- 25 Days or Less
- 46 Days or Less
- 49 Days or Less
- 50 Days or Less
- 57 Days or Less
- 60 Days or Less
- 69 Days or Less
- 70 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
