UNITRONIC® BUS PB BURIAL FC

UNITRONIC® BUS PB BURIAL FC
  • Volume Discount
Bus cable for PROFIBUS-DP, -FMS and FIP. Rugged, UV- and weather-resistant. Temperature range from -40°C bis +60°CSuitable for outdoor use and direct burial, UV-resistant

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
2170323/100
2170323/1000
2170323/300
2170323/500
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
RoHSLength
(m)

305.62 €

1 Available 5 Days 10100

3,056.12 €

1 Available 8 Days 101000

916.83 €

1 Available 5 Days 10300

1,528.05 €

1 Available 5 Days 10500

Loading...

  1. 1

Basic information

Category Other No. of Cores 2 Core (2C) Cable Outer Diameter(mm) 10.0 or More
Color Black Sheath Material PE Diameter conductor 0,64
Operating temperature, fix 60 Conductor category Class 1 = solid Conductor material Cu, bare
Core insulation Foam PE Core identification Colour Flame retardant No
Halogen free (acc. EN 50267-2-2) False Low smoke (acc. EN 61034-2) False Screen over stranding Foil + braiding
Screen over stranding element None Stranding element Pairs Outer diameter approx.(mm) 10,4
Number of cores(Core) 2 Colour outer sheath Black Category Other
Material outer sheath PE
