PSM measurement modules with CAN bus for PSM busbars
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 7859410 |
| 7859420 |
| 7859430 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Number of outputs | Type of connector | |
|---|---|---|---|---|---|---|---|
778.56 € | 1 | Available | 7 Days | 8 | IEC 60320 C13 | ||
814.67 € | 1 | Available | 7 Days | 6 | IEC 60320 C19 (+ 2 C13) | ||
795.89 € | 1 | Available | 7 Days | 6 | Earthingpin CEE7/3 (+ 2 C13) |
Loading...
Basic information
| Length(mm) | 500 | Width(mm) | 53 | Cross-section(mm²) | 2.5 |
|---|---|---|---|---|---|
| Max. rated operation voltage DC AC(V) | 24 | Rated surge voltage(kV) | 6 | Number of phases | 3 |
| Number of poles | 3 | Suitable for | Devices with auxiliary switch/N-busbar | Type of electric connection | Other |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
