Bullet connector Sleeve socket Series (connectors): NCC

Bullet connector Sleeve socket Series (connectors): NCC

Click on this image to zoom in.

Click on this image to zoom in.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
09 0774 000 08
09 0774 090 08
Part NumberRelated to
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
Nominal current
(A)
Max. temperature
(°C)

15.89 €

1 Available 3 Days 10+100

15.95 €

1 Available 3 Days 5+85

Loading...

  1. 1

Basic information

Nominal voltage(V) 250 Cable Ø (max.)(mm) 4 Cable Ø (min.)(mm) 3
Connection angle(°) 180 Cross section (max.)(mm²) 0.25 Cross-section range 0.25 mm² (max)
Min. temperature(°C) -40 Number of pins 8 Total number of pins 8
Series (connectors) NCC Connection (components) Soldering Connector type Sleeve socket
Connector type (category) Bullet connector Contact material Au
