M16 flange plug 16-pin

M16 flange plug 16-pin
  • Volume Discount

Product Details:

Manufacturer part number: 09 0507 300 16

Brand: BINDER

Price: 20.23

Delivery time: 3 Days

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

09 0507 300 16

Part Number
09 0507 300 16
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?

20.23 €

1 Available 3 Days

Loading...

  1. 1

Basic information

Nominal current(A) 3 Nominal voltage(V) 60 AWG 24
Connection angle(°) 180 Cross section (max.)(mm²) 0.25 Cross-section range 0.25 mm² (max)
Max. temperature(°C) +95 Min. temperature(°C) -40 Number of pins 16
Total number of pins 16 Case material PBT, UL94V-0 Connection (components) Soldering
Connector type Sleeve plug Connector type (category) Mini DIN connector Contact material CuZn
Leading contact (PE) No Seal type Screws

This page is M16 flange plug 16-pin, part number 09 0507 300 16.
You can find the detail information about specifications and dimensions on part number 09 0507 300 16.
