Configure

Nominal current(A)
- 10
Nominal voltage(V)
- 160
Connection direction
- right angle
Product size (height)(mm)
- 11.40
- 14
Product size (length)(mm)
- 7.00
- 10.5
- 11.40
Product size (width)(mm)
- 14
- 17.5
- 28.00
- 42.00
Cross section (max.)(mm²)
- 1.5
Min. cross section(mm²)
- 0.2
AWG max.
- 14
AWG (min.)
- 24
Contact spacing(mm)
- 3.50
Stripping length (max.)(mm)
- 9
Total number of pins
- 2
- 3
- 4
- 5
- 6
- 8
- 12
Pins per row
- 2
- 3
- 4
- 5
- 6
- 8
- 12
Contact material
- Cathode copper
Case material
- Polyphthalamide (PPA GF)
Pin strip type (category)
- Pin enclosure - PCB
- Receptacles (standard)
Connector type
- Pin strip
Connector features
- + strap handle
Connection (components)
- Print
Connector contact surface
- Tin plated
Industrial goods
- No
- Yes
Est. shipping days
- All
- Within 3 working days
- Within 6 working days
- Within 29 working days

1-conductor female plug 2091【1 to 200 pieces】

Catalog

Part number:

Still undefined. 12 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

2091-1102/0002-0000
2091-1103/0002-0000
2091-1104/0002-0000
2091-1105/0002-0000
2091-1106/0002-0000
2091-1122
2091-1123
2091-1124
2091-1125
2091-1128
2091-1130
2091-1132

Nominal current

(A)

Nominal voltage

(V)

Connection direction

Product size (height)

(mm)

Product size (length)

(mm)

Product size (width)

(mm)

Cross section (max.)

(mm²)

Min. cross section

(mm²)

AWG max.

AWG (min.)

Contact spacing

(mm)

Stripping length (max.)

(mm)

Total number of pins

Pins per row

Contact material

Case material

Pin strip type (category)

Connector type

Connector features

Connection (components)

Connector contact surface

Industrial goods

Minimum order quantity

-	-	-	-	-	-	-	-	-	-	-	-	-	2	2	-	-	Receptacles (standard)	-	-	-	-	No	1 pieces
-	-	-	-	-	-	-	-	-	-	-	-	-	3	3	-	-	Receptacles (standard)	-	-	-	-	No	1 pieces
-	-	-	-	-	-	-	-	-	-	-	-	-	4	4	-	-	Receptacles (standard)	-	-	-	-	No	1 pieces
-	-	-	-	-	-	-	-	-	-	-	-	-	5	5	-	-	Receptacles (standard)	-	-	-	-	No	1 pieces
-	-	-	-	-	-	-	-	-	-	-	-	-	6	6	-	-	Receptacles (standard)	-	-	-	-	No	1 pieces
Data sheet	10	160	right angle	11.40	7.00	14	1.5	0.2	14	24	3.50	9	2	2	Cathode copper	Polyphthalamide (PPA GF)	Pin enclosure - PCB	Pin strip	+ strap handle	Print	Tin plated	Yes	1 packs 200 pieces
Data sheet	10	160	right angle	11.40	10.5	14	1.5	0.2	14	24	3.50	9	3	3	Cathode copper	Polyphthalamide (PPA GF)	Pin enclosure - PCB	Pin strip	+ strap handle	Print	Tin plated	Yes	1 packs 200 pieces
Data sheet	10	160	right angle	14	11.40	14	1.5	0.2	14	24	3.50	9	4	4	Cathode copper	Polyphthalamide (PPA GF)	Pin enclosure - PCB	Pin strip	+ strap handle	Print	Tin plated	Yes	1 packs 200 pieces
Data sheet	10	160	right angle	14	11.40	17.5	1.5	0.2	14	24	3.50	9	5	5	Cathode copper	Polyphthalamide (PPA GF)	Pin enclosure - PCB	Pin strip	+ strap handle	Print	Tin plated	Yes	1 packs 200 pieces
Data sheet	10	160	right angle	14	11.40	28.00	1.5	0.2	14	24	3.50	9	8	8	Cathode copper	Polyphthalamide (PPA GF)	Pin enclosure - PCB	Pin strip	+ strap handle	Print	Tin plated	Yes	1 packs 100 pieces
Data sheet	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1 packs 100 pieces
Data sheet	10	160	right angle	14	11.40	42.00	1.5	0.2	14	24	3.50	9	12	12	Cathode copper	Polyphthalamide (PPA GF)	Pin enclosure - PCB	Pin strip	+ strap handle	Print	Tin plated	Yes	1 packs 100 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

2.57 € ( 3.06 € )	3 working days
3.40 € ( 4.05 € )	3 working days
3.93 € ( 4.68 € )	3 working days
4.71 € ( 5.60 € )	3 working days
5.23 € ( 6.22 € )	3 working days
308.12 € ( 366.66 € )	6 working days
420.17 € ( 500.00 € )	6 working days
503.08 € ( 598.67 € )	6 working days
633.05 € ( 753.33 € )	6 working days
503.08 € ( 598.67 € )	29 working days
633.05 € ( 753.33 € )	6 working days
756.31 € ( 900.01 € )	29 working days
