4-conductor terminal strip 264【25-100 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 264-203 |
| 264-205 |
| 264-206 |
| 264-207 |
| 264-208 |
| 264-209 |
| 264-210 |
| 264-211 |
| 264-212 |
| 264-252 |
| 264-253 |
| 264-254 |
| 264-255 |
| 264-256 |
| 264-257 |
| 264-258 |
| 264-259 |
| 264-260 |
| 264-261 |
| 264-262 |
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Number of pins (Pole) | Product size (length) (mm) | Product size (width) (mm) | Stripping length (max.) (mm) | Min. cross section (flexible) (mm²) | No. of rows | Weight (g) | Connector features | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
545.48 € | 100 Pieces Per Package | 1 pack | Available | 7 Days | - | - | - | - | - | - | - | - | ||
335.01 € | 50 Pieces Per Package | 1 pack | 7 Days | 5 | 66 | 66 | 8 | 0.50 | 5 | 33.3 | + sleeve | |||
512.68 € | 50 Pieces Per Package | 1 pack | Available | 7 Days | 6 | 76 | 76 | 8 | 0.50 | 6 | 43.15 | + sleeve | ||
525.49 € | 50 Pieces Per Package | 1 pack | 7 Days | 7 | 86 | 86 | 8 | 0.50 | 7 | 45.7 | + sleeve | |||
1,186.56 € | 100 Pieces Per Package | 1 pack | 8 Days | - | - | - | - | - | - | - | - | |||
581.51 € | 50 Pieces Per Package | 1 pack | 8 Days | 9 | - | 106 | 9 | 0.08 | 9 | - | + sleeve | |||
368.63 € | 25 Pieces Per Package | 1 pack | 7 Days | - | - | - | - | - | - | - | - | |||
464.59 € | 25 Pieces Per Package | 1 pack | Available | 25 Days | 11 | - | 126 | 9 | 0.08 | 11 | - | + sleeve | ||
386.56 € | 25 Pieces Per Package | 1 pack | 7 Days | 12 | - | 136 | 9 | 0.08 | 12 | - | + sleeve | |||
335.01 € | 100 Pieces Per Package | 1 pack | 25 Days | 2 | - | 27 | 9 | 0.08 | 2 | - | + latch lock base | |||
545.48 € | 100 Pieces Per Package | 1 pack | Available | 7 Days | 3 | - | 37 | 9 | 0.08 | 3 | - | + latch lock base | ||
355.27 € | 50 Pieces Per Package | 1 pack | Available | 7 Days | 4 | 47 | 47 | 8 | 0.50 | 4 | 27.48 | + latch lock base | ||
760.79 € | 100 Pieces Per Package | 1 pack | 26 Days | 5 | - | 57 | 9 | 0.08 | 5 | - | + latch lock base | |||
512.68 € | 50 Pieces Per Package | 1 pack | Available | 25 Days | 6 | - | 67 | 9 | 0.08 | 6 | - | + latch lock base | ||
525.49 € | 50 Pieces Per Package | 1 pack | 26 Days | 7 | - | 77 | 9 | 0.08 | 7 | - | + latch lock base | |||
599.44 € | 50 Pieces Per Package | 1 pack | 25 Days | 8 | - | 87 | 9 | 0.08 | 8 | - | + latch lock base | |||
666.67 € | 50 Pieces Per Package | 1 pack | 25 Days | 9 | - | 97 | 9 | 0.08 | 9 | - | + latch lock base | |||
420.87 € | 25 Pieces Per Package | 1 pack | Available | 25 Days | 10 | - | 107 | 9 | 0.08 | 10 | - | + latch lock base | ||
464.59 € | 25 Pieces Per Package | 1 pack | Available | 25 Days | 11 | - | 117 | 9 | 0.08 | 11 | - | + latch lock base | ||
501.75 € | 25 Pieces Per Package | 1 pack | Available | 25 Days | 12 | - | 127 | 9 | 0.08 | 12 | - | + latch lock base |
Loading...
Basic information
| Product size (height)(mm) | 22.10 | Clamp width(mm) | 10 | Min. stripping length(mm) | 8 |
|---|---|---|---|---|---|
| Nominal current(A) | 24 | Nominal voltage(V) | 800 | Max. cross section (flexible)(mm²) | 2.50 |
| Min. cross section (inflexible)(mm²) | 0.08 | Max. cross section (inflexible)(mm²) | 2.5 | AWG (min.) | 28 |
| AWG max. | 14 | Pins per row | 4 | Contamination level | 3 |
| Colour | Grey | Connector type (category) | Punch-down block | Configuration | L |
| Connection (components) | Pull spring | Industrial goods | Yes |
Configure
Basic Attributes
-
Number of pins(Pole)
-
Product size (length)(mm)
-
Product size (width)(mm)
-
Stripping length (max.)(mm)
-
Min. cross section (flexible)(mm²)
-
No. of rows
-
Weight(g)
-
Connector features
- + latch lock base
- + sleeve
Filter by standard shipping days
-
- All
- 7 Days or Less
- 8 Days or Less
- 25 Days or Less
- 26 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
