Double feed-through terminal 2001【100 Pieces Per Package】

Double feed-through terminal 2001

Product Details:

Manufacturer part number: 2001-1441

Brand: WAGO

Price: 184.87

Delivery time: 8 Days

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

2001-1441

Part Number
2001-1441
Part NumberRelated to
Standard Unit Price
Number of pc(s). included in pkg.Minimum order quantityVolume Discount
Standard
Shipping Days
?

184.87 €

100 Pieces Per Package

1 pack 8 Days

Loading...

  1. 1

Basic information

Number of pins(Pole) 2 Product size (height)(mm) 32.90 Product size (length)(mm) 4.2
Product size (width)(mm) 4.2 Clamp width(mm) 4.20 Stripping length (max.)(mm) 9
Nominal current(A) 18 Nominal voltage(V) 800 Min. cross section (flexible)(mm²) 0.25
Max. cross section (flexible)(mm²) 2.50 Min. cross section (inflexible)(mm²) 0.25 Max. cross section (inflexible)(mm²) 1.5
AWG (min.) 22 AWG max. 14 No. of rows 1
Pins per row 4 Contamination level 3 Weight(g) 6.143
Colour Grey Connector type (category) Continuity Configuration L
Connection (components) Pull spring Industrial goods Yes

This page is Double feed-through terminal 2001, part number 2001-1441.
You can find the detail information about specifications and dimensions on part number 2001-1441.
