3-conductor sensor LED terminal block 2000

3-conductor sensor LED terminal block 2000

Click on this image to zoom in.

Click on this image to zoom in.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
2000-5311/1101-951
2000-5311/1102-950
Part NumberRelated toStandard Unit PriceVolume DiscountShipping Days?

561.15 €

Available 28 Days

623.91 €

Available 28 Days

Loading...

  1. 1

Basic information

Number of pins(Pole) 8 Content(pc(s)) 50 Clamp width(mm) 7
Stripping length (max.)(mm) 11 Min. stripping length(mm) 9 Nominal current(A) 13.5
Nominal voltage(V) 24 Min. cross section (flexible)(mm²) 0.14 Max. cross section (flexible)(mm²) 1.5
Min. cross section (inflexible)(mm²) 0.14 Max. cross section (inflexible)(mm²) 1.5 AWG (min.) 24
AWG max. 16 No. of rows 3 Pins per row 2
Colour Grey Connector type (category) Proximity switch terminal Connection (components) Pull spring
Industrial goods Yes
