3-conductor through terminal 880

3-conductor through terminal 880

Click on this image to zoom in.

Click on this image to zoom in.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
880-661/999-940
880-662
880-662/999-940
880-664
880-664/999-940
880-681
880-681/999-940
880-682
880-682/999-940
880-684
880-684/999-940
Part NumberRelated toStandard Unit PriceVolume DiscountShipping Days?Content
(pc(s))
Nominal voltage
(V)
Weight
(g)
Colour Configuration Connector features

99.99 €

Available 3 Days 5040010.721GreyL+ shielding conductor

102.09 €

Available 3 Days 5040010.701Orange-+ shielding conductor

102.09 €

Available 3 Days 5040010.711Orange-+ shielding conductor

102.09 €

Available 3 Days 5040010.701BlueN+ shielding conductor

102.09 €

Available 3 Days 5040010.711BlueN+ shielding conductor

130.49 €

Available 3 Days 1008008.679GreyL-

130.49 €

Available 3 Days 1008008.679GreyL-

135.76 €

Available 3 Days 1008008.679Orange--

135.76 €

Available 3 Days 1008008.679Orange--

135.76 €

Available 3 Days 1008008.679BlueN-

135.76 €

Available 3 Days 1008008.679BlueN-

Loading...

  1. 1

Basic information

Number of pins(Pole) 3 Product size (height)(mm) 29 Product size (length)(mm) 5
Product size (width)(mm) 5 Clamp width(mm) 5 Stripping length (max.)(mm) 8
Nominal current(A) 25 Min. cross section (flexible)(mm²) 0.08 Max. cross section (flexible)(mm²) 4
Min. cross section (inflexible)(mm²) 0.08 Max. cross section (inflexible)(mm²) 4 AWG (min.) 28
AWG max. 12 No. of rows 1 Pins per row 3
Contamination level 3 Connector type (category) Continuity Connection (components) Pull spring
Industrial goods Yes
