1-conductor / 1-pin disconnect carrier terminal block 769【50 Pieces Per Package】
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 769-212 |
| 769-213 |
| 769-232 |
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Nominal voltage (V) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|
158.49 € | 50 Pieces Per Package | 1 pack | Available | 8 Days | 400 | 9 | ||
185.83 € | 50 Pieces Per Package | 1 pack | Available | 26 Days | 250 | 11.9 | ||
141.61 € | 50 Pieces Per Package | 1 pack | Available | 7 Days | 400 | 5.566 |
Loading...
Basic information
| Number of pins(Pole) | 1 | Product size (height)(mm) | 28.5 | Product size (length)(mm) | 5 |
|---|---|---|---|---|---|
| Product size (width)(mm) | 5 | Clamp width(mm) | 5 | Stripping length (max.)(mm) | 8 |
| Nominal current(A) | 16 | Min. cross section (flexible)(mm²) | 0.08 | Max. cross section (flexible)(mm²) | 4 |
| Min. cross section (inflexible)(mm²) | 0.08 | Max. cross section (inflexible)(mm²) | 4 | AWG (min.) | 28 |
| AWG max. | 12 | No. of rows | 1 | Pins per row | 2 |
| Contamination level | 3 | Colour | Grey | Connector type (category) | Base terminal |
| Configuration | L | Connection (components) | Pull spring | Industrial goods | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
