2-conductor disconnect / test terminal block 282【20-25 Pieces Per Package】

2-conductor disconnect / test terminal block 282

Click on this image to zoom in.

Click on this image to zoom in.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
282-135
282-860
Part NumberRelated to
Standard Unit Price
Number of pc(s). included in pkg.Minimum order quantityVolume Discount
Standard
Shipping Days
?
Number of pins
(Pole)
Product size (height)
(mm)
Nominal current
(A)
Nominal voltage
(V)
Pins per row

125.27 €

25 Pieces Per Package

1 pack Available 9 Days 237414002

212.88 €

20 Pieces Per Package

1 pack 75 Days 175305003

Loading...

  1. 1

Basic information

Product size (width)(mm) 8 Clamp width(mm) 8 Stripping length (max.)(mm) 13
Min. stripping length(mm) 12 Min. cross section (flexible)(mm²) 0.2 Max. cross section (flexible)(mm²) 6
Min. cross section (inflexible)(mm²) 0.2 Max. cross section (inflexible)(mm²) 6 AWG (min.) 24
AWG max. 10 No. of rows 1 Contamination level 3
Colour Grey Connector type (category) N terminal Configuration L
Connection (components) Pull spring Connector features + test option Industrial goods Yes
