2-conductor ground terminal block 280【100 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 280-607 |
| 280-907 |
| 280-907/999-950 |
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Nominal current (A) | Connector features | |
|---|---|---|---|---|---|---|---|---|
490.83 € | 100 Pieces Per Package | 1 pack | Available | 25 Days | - | - | ||
420.17 € | 100 Pieces Per Package | 1 pack | 25 Days | 24 | - | |||
497.37 € | 100 Pieces Per Package | 1 pack | Available | 7 Days | 24 | Complies with ATEX Ex-e II standards |
Loading...
Basic information
| Number of pins(Pole) | 1 | Product size (height)(mm) | 28 | Product size (width)(mm) | 5 |
|---|---|---|---|---|---|
| Clamp width(mm) | 5 | Stripping length (max.)(mm) | 9 | Min. stripping length(mm) | 8 |
| Min. cross section (flexible)(mm²) | 0.08 | Max. cross section (flexible)(mm²) | 2.50 | Min. cross section (inflexible)(mm²) | 0.08 |
| Max. cross section (inflexible)(mm²) | 2.5 | AWG (min.) | 28 | AWG max. | 14 |
| No. of rows | 1 | Pins per row | 2 | Colour | Green-yellow |
| Connector type (category) | PG terminal | Configuration | Terre | Connection (components) | Pull spring |
| Industrial goods | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
