2-conductor protective conductor terminal 780【50 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 780-607 |
| 780-607/999-950 |
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | |
|---|---|---|---|---|---|---|
251.40 € | 50 Pieces Per Package | 1 pack | Available | 8 Days | ||
256.88 € | 50 Pieces Per Package | 1 pack | Available | 25 Days |
Loading...
Basic information
| Number of pins(Pole) | 1 | Product size (height)(mm) | 43.50 | Product size (length)(mm) | 5 |
|---|---|---|---|---|---|
| Product size (width)(mm) | 5 | Clamp width(mm) | 5 | Stripping length (max.)(mm) | 8 |
| Nominal current(A) | 24 | Min. cross section (flexible)(mm²) | 0.08 | Max. cross section (flexible)(mm²) | 2.50 |
| Min. cross section (inflexible)(mm²) | 0.08 | Max. cross section (inflexible)(mm²) | 2.5 | AWG (min.) | 28 |
| AWG max. | 14 | No. of rows | 1 | Pins per row | 2 |
| Weight(g) | 13.68 | Colour | Green-yellow | Connector type (category) | PG terminal |
| Configuration | Terre | Connection (components) | Pull spring | Industrial goods | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
