THR PCB terminal block【160-560 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Number of pins (Pole) | AWG max. | Contact spacing (mm) | Max. cross section (inflexible) (mm²) | Min. cross section (inflexible) (mm²) | Max. cross section (flexible) (mm²) | Min. stripping length (mm) | Stripping length (max.) (mm) | Pins per row | Nominal current (A) | Nominal voltage (V) | Product size (height) (mm) | Product size (length) (mm) | Product size (width) (mm) | PCB terminal features | Actuation direction | Contact material | Insulation material | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
311.55 € | 560 Pieces Per Package | 1 pack | Available | 4 Days | 2 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 2 | - | 400 | 12 | 8.5 | 15.5 | + PUSH WIRE® | - | - | - | ||
257.69 € | 560 Pieces Per Package | 1 pack | 7 Days | 2 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 2 | - | 320 | 12 | 8.5 | 15.5 | + CAGE CLAMP® | - | - | - | |||
344.33 € | 400 Pieces Per Package | 1 pack | Available | 4 Days | 3 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 3 | - | 400 | 12 | 12 | 15.5 | + PUSH WIRE® | - | - | - | ||
285.72 € | 400 Pieces Per Package | 1 pack | 7 Days | 3 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 3 | - | 320 | 12 | 12 | 15.5 | + CAGE CLAMP® | - | - | - | |||
301.40 € | 300 Pieces Per Package | 1 pack | 7 Days | 4 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 4 | - | 320 | 15.50 | 12 | 15.5 | + CAGE CLAMP® | - | - | - | |||
301.40 € | 240 Pieces Per Package | 1 pack | 7 Days | 5 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 5 | - | 320 | 15.50 | 12 | 19 | + CAGE CLAMP® | - | - | - | |||
355.27 € | 200 Pieces Per Package | 1 pack | Available | 4 Days | 6 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 6 | - | 400 | 15.50 | 12 | 22.5 | + PUSH WIRE® | - | - | - | ||
296.92 € | 200 Pieces Per Package | 1 pack | 7 Days | 6 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 6 | - | 320 | 15.50 | 12 | 22.5 | + CAGE CLAMP® | - | - | - | |||
370.57 € | 180 Pieces Per Package | 1 pack | Available | 4 Days | 7 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 7 | - | 400 | 15.50 | 12 | 26 | + PUSH WIRE® | - | - | - | ||
319.33 € | 180 Pieces Per Package | 1 pack | 7 Days | 7 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 7 | - | 320 | 15.50 | 12 | 26 | + CAGE CLAMP® | - | - | - | |||
381.51 € | 160 Pieces Per Package | 1 pack | Available | 4 Days | 8 | 16 | 3.50 | 1.50 | 0.2 | 1.50 | 6 | 9 | 8 | - | 400 | 15.50 | 12 | 29.5 | + PUSH WIRE® | - | - | - | ||
402.24 € | 520 Pieces Per Package | 1 pack | 4 Days | 3 | 20 | 2.50 | 0.50 | 0.14 | 0.50 | 6 | 8 | 3 | 10 | 250 | 12 | 9.00 | 16.70 | + PUSH WIRE® | Perpendicular (to the PCB) | Copper alloy | Polyamide | |||
468.95 € | 400 Pieces Per Package | 1 pack | Available | 4 Days | 4 | 20 | 2.50 | 0.50 | 0.14 | 0.50 | 7 | 8 | 4 | 10 | 250 | 12 | 11.50 | 16.70 | + PUSH WIRE® | Perpendicular (to the PCB) | Copper alloy | Polyamide | ||
442.57 € | 340 Pieces Per Package | 1 pack | 4 Days | 5 | 20 | 2.50 | 0.50 | 0.14 | 0.50 | 7 | 8 | 5 | 10 | 250 | 14.00 | 12 | 16.70 | + PUSH WIRE® | Perpendicular (to the PCB) | Copper alloy | Polyamide | |||
442.57 € | 280 Pieces Per Package | 1 pack | 4 Days | 6 | 20 | 2.50 | 0.50 | 0.14 | 0.50 | 6 | 8 | 6 | 10 | 250 | 16.50 | 12 | 16.70 | + PUSH WIRE® | Perpendicular (to the PCB) | Copper alloy | Polyamide | |||
490.83 € | 240 Pieces Per Package | 1 pack | Available | 4 Days | 7 | 20 | 2.50 | 0.50 | 0.14 | 0.50 | 8 | 8 | 7 | 10 | 250 | 16.70 | 12 | 19 | + PUSH WIRE® | Perpendicular (to the PCB) | Copper alloy | Polyamide | ||
464.99 € | 220 Pieces Per Package | 1 pack | 4 Days | 8 | 20 | 2.50 | 0.50 | 0.14 | 0.50 | 8 | 8 | 8 | 10 | 250 | 16.70 | 12 | 21.50 | + PUSH WIRE® | Perpendicular (to the PCB) | Copper alloy | Polyamide |
Loading...
Basic information
| Color | Black | AWG (min.) | 24 | Min. cross section (flexible)(mm²) | 0.20 |
|---|---|---|---|---|---|
| No. of rows | 1 | Series (connectors) | 250 | Connection (components) | |
| PCB terminal type (category) | Spring-loaded terminal | Connector orientation | At an angle (to the PCB) | Industrial goods | Yes |
| Wire protection | Yes |
Configure
Basic Attributes
-
Number of pins(Pole)
-
AWG max.
- 16
- 20
-
Contact spacing(mm)
-
Max. cross section (inflexible)(mm²)
-
Min. cross section (inflexible)(mm²)
- 0.14
- 0.2
-
Max. cross section (flexible)(mm²)
-
Min. stripping length(mm)
-
Stripping length (max.)(mm)
-
Pins per row
-
Nominal current(A)
-
Nominal voltage(V)
-
Product size (height)(mm)
-
Product size (length)(mm)
-
Product size (width)(mm)
-
PCB terminal features
- + CAGE CLAMP®
- + PUSH WIRE®
-
Actuation direction
- Perpendicular (to the PCB)
-
Contact material
- Copper alloy
-
Insulation material
- Polyamide
Filter by standard shipping days
-
- All
- 4 Days or Less
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
