Plug, 3-pole, 890【1-50 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 890-213 |
| 890-233 |
| 890-253 |
| 890-253/060-000 |
| 890-293 |
| 890-293/082-000 |
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Product size (height) (mm) | Product size (width) (mm) | Product size (depth) (mm) | Nominal current (details) (A) | Nominal voltage (details) (V) | AWG | Cable diameter (mm²) | Cable dia. (max.) (mm²) | Cable dia. (min.) (mm²) | Total number of pins | Contact material | Connection | Type (misc.) | Colour | Coding | Leading contact (PE) | Industrial goods | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3.11 € | 1 | Available | 4 Days | - | - | - | 16 | 250 | 22 -16 | 25 -1.5 mm | 1.5 | 0.25 | 2 + PE | - | CAGE CLAMP® S | Without strain relief housing | Black | A | Yes | - | |||
158.49 € | 50 Pieces Per Package | 1 pack | Available | 7 Days | 11.7 | 15 | 34.1 | - | - | 22 - 16 | - | - | - | 3 | Copper alloy | - | - | White | A | - | Yes | ||
180.36 € | 50 Pieces Per Package | 1 pack | Available | 7 Days | 11.7 | 15 | 34.1 | - | - | 22 - 16 | - | - | - | 3 | Copper alloy | - | - | Grey | B | - | Yes | ||
240.48 € | 50 Pieces Per Package | 1 pack | Available | 7 Days | 11.7 | 15 | 34.1 | - | - | 22 - 16 | - | - | - | 3 | Copper alloy | - | - | Grey | B | - | Yes | ||
235.01 € | 50 Pieces Per Package | 1 pack | Available | 7 Days | 11.7 | 15 | 34.1 | - | - | 22 - 16 | - | - | - | 3 | Copper alloy | - | - | Pink | B | - | Yes | ||
169.43 € | 50 Pieces Per Package | 1 pack | Available | 7 Days | 11.7 | 15 | - | - | - | 22 - 16 | - | - | - | 3 | Copper alloy | - | - | Pink | B | - | Yes |
Loading...
Basic information
| Nominal current(A) | 16 | Nominal voltage(V) | 250 | Connection direction | straight |
|---|---|---|---|---|---|
| Connector type (category) | Mains connector | Connector type | Plug | Connection (components) | Pull spring |
| Series (mains connectors) | WINSTA MINI |
Configure
Basic Attributes
-
Product size (height)(mm)
-
Product size (width)(mm)
-
Product size (depth)(mm)
-
Nominal current (details)(A)
- 16
-
Nominal voltage (details)(V)
- 250
-
AWG
-
Cable diameter(mm²)
- 25 -1.5 mm
-
Cable dia. (max.)(mm²)
- 1.5
-
Cable dia. (min.)(mm²)
- 0.25
-
Total number of pins
-
Contact material
- Copper alloy
-
Connection
- CAGE CLAMP® S
-
Type (misc.)
-
Colour
- Black
- Grey
- Pink
- White
-
Coding
- A
- B
-
Leading contact (PE)
- Yes
-
Industrial goods
- Yes
Filter by standard shipping days
-
- All
- 4 Days or Less
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
