Bus system flat-type plug SACC-E, socket M12-SPEEDCON, D-coded, front / screw mounting, with TPE litz wire
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
1535202
Basic information
| Connection side A (sensors/actuators) | Cable, open end | Connection side B (sensors/actuators) | socket, built-in | Cable length(m) | 0.5 |
|---|---|---|---|---|---|
| Number of pins | 4 | Nominal current(A) | 4 | Nominal voltage(V AC) | 250 |
| IP rating | IP67 | Thread type connection side | M12 | Coding | D |
| Connection (components) | Open end cable | Connector standard | Sensor connector | Connector type | Socket |
| Jacket material | PUR | Sensor/actuator wiring type (category) | Sensor/actuator built-in connector | Connection direction | Built-in |
This page is Bus system flat-type plug SACC-E, socket M12-SPEEDCON, D-coded, front / screw mounting, with TPE litz wire, part number 1535202.
You can find the detail information about specifications and dimensions on part number 1535202.
Configure
Basic Attributes
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
