Multi-level terminal block PT 1,5 / S
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 3213713 |
| 3213726 |
| 3213742 |
| 3213755 |
| 3213768 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Color | AWG | Connector type (category) | |
|---|---|---|---|---|---|---|---|---|
2.62 € | 100 | 7 Days | Grey | 26 - 14 | Multiport terminal | |||
2.62 € | 100 | 7 Days | Blue | 26 - 14 | Multiport terminal | |||
4.52 € | 50 | 7 Days | Grey | 26 - 14 | Multiport terminal | |||
4.59 € | 50 | 72 Days | Grey | 26 - 16 | Tripleport PG terminal | |||
4.59 € | 50 | 72 Days | Grey | 26 - 16 | Tripleport PG terminal |
Loading...
Basic information
| Total number of pins(Pole) | 6 | Clamp width(mm) | 3.5 | Connector cross section (fixed)(mm²) | 0.14 - 1.5 |
|---|---|---|---|---|---|
| Connector cross-section (flexible)(mm²) | 0.14 - 1.5 | Nominal voltage(V) | 500 | Nominal current(A) | 15 |
| No. of rows | 3 | Product size (height)(mm) | 53.2 | Product size (length)(mm) | 97.2 |
| Product size (width)(mm) | 3.5 | Stripping length(mm) | 8-10 | Flammability rating | V0 |
| Connection (components) | Quick-connect | Insulation material | PA | Industrial goods | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
