Multi-level terminal block PTTBS 1,5 / S
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 3214495 |
| 3214496 |
| 3214505 |
| 3214521 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Total number of pins (Pole) | Color | AWG | Connector cross section (fixed) (mm²) | Connector cross-section (flexible) (mm²) | Pins per row | Product size (width) (mm) | Stripping length (mm) | Connection (components) | Insulation material | Industrial goods | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1.56 € | 150 | 7 Days | 4 | Grey | 26 - 14 | 0.14 - 1.5 | 0.14 - 1.5 | - | 3.5 | 8-10 | Quick-connect | PA | Yes | |||
1.56 € | 150 | 7 Days | - | Grey | - | 0.14 - 1.50 | 0.14 - 1.50 | 2 | - | - | Pull spring | - | - | |||
1.56 € | 150 | 75 Days | 4 | Blue | 26 - 14 | 0.14 - 1.5 | 0.14 - 1.5 | - | 3.5 | 8-10 | Quick-connect | PA | Yes | |||
3.55 € | 100 | 75 Days | 4 | Grey | 26 - 14 | 0.14 - 1.5 | 0.14 - 1.5 | - | 3.5 | 8-10 | Quick-connect | PA | Yes |
Loading...
Basic information
| Clamp width(mm) | 3.5 | Nominal voltage(V) | 500 | Nominal current(A) | 16 |
|---|---|---|---|---|---|
| No. of rows | 2 | Product size (height)(mm) | 55 | Product size (length)(mm) | 78 |
| Flammability rating | V0 | Connector type (category) | Dualport terminal |
Configure
Basic Attributes
-
Total number of pins(Pole)
-
Color
- Blue
- Grey
-
AWG
-
Connector cross section (fixed)(mm²)
-
Connector cross-section (flexible)(mm²)
-
Pins per row
-
Product size (width)(mm)
-
Stripping length(mm)
-
Connection (components)
-
Insulation material
- PA
-
Industrial goods
- Yes
Filter by standard shipping days
-
- All
- 7 Days or Less
- 75 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
