Power terminal block STIO-IN 2,5 / 3
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Basic information
| Total number of pins(Pole) | 4 | Color | Orange | Clamp width(mm) | 10.4 |
|---|---|---|---|---|---|
| Connector cross section (fixed)(mm²) | 0.08 - 4 | Connector cross-section (flexible)(mm²) | 0.08 - 2.5 | Contamination level | 3 |
| Nominal voltage(V) | 250 | Nominal current(A) | 30 | Product size (height)(mm) | 44.5 |
| Product size (length)(mm) | 75 | Product size (width)(mm) | 10.4 | Stripping length(mm) | 8-10 |
| Flammability rating | V0 | Connection (components) | Pull spring | Insulation material | PA |
| Industrial goods | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
