Ground modular terminal block UT 16-PE

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

3044212

Part Number
3044212
Part NumberRelated to
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?

6.16 €

50 7 Days

Loading...

  1. 1

Basic information

Total number of pins(Pole) 2 Color Green-yellow AWG 16 - 4
Clamp width(mm) 12.2 Connector cross section (fixed)(mm²) 1.5 - 25 Connector cross-section (flexible)(mm²) 1.5 - 25
Contamination level 3 Nominal current(A) 76 No. of rows 1
Product size (height)(mm) 54.4 Product size (length)(mm) 55.5 Product size (width)(mm) 12.2
Stripping length(mm) 14(max.) Flammability rating V0 Connection (components) Screws
Connector type (category) Tripleport PG terminal Insulation material PA Industrial goods Yes

This page is Ground modular terminal block UT 16-PE, part number 3044212.
You can find the detail information about specifications and dimensions on part number 3044212.
