Installation terminal block UTI 16
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Basic information
| Total number of pins(Pole) | 2 | AWG | 10 - 4 | Clamp width(mm) | 12.2 |
|---|---|---|---|---|---|
| Connector cross section (fixed)(mm²) | 6 - 25 | Connector cross-section (flexible)(mm²) | 6 - 16 | Nominal voltage(V) | 400 |
| Nominal current(A) | 76 | No. of rows | 1 | Product size (height)(mm) | 49.9 |
| Product size (length)(mm) | 51 | Product size (width)(mm) | 12.2 | Stripping length(mm) | 12(max.) |
| Flammability rating | V2 | Connection (components) | Plug & Clip | Connector type (category) | Continuity |
| Industrial goods | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
