Fuse modular terminal block UT 4-HESI
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 3046032 |
| 3060527 |
| 3074169 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Total number of pins (Pole) | Color | AWG | Nominal current (details) (A) | Product size (width) (mm) | Stripping length (mm) | Connector type (category) | Insulation material | Industrial goods | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
6.40 € | 50 | 7 Days | 2 | Black | 26 - 10 | 6.3 | 6.2 | 9(max.) | Fuse serial terminal | PA | No | |||
6.40 € | 50 | 7 Days | - | Blue | - | - | - | - | Fuse box feed-trough terminal | - | - | |||
6.40 € | 50 | 7 Days | - | Grey | - | - | - | - | Fuse box feed-trough terminal | - | - |
Loading...
Basic information
| Clamp width(mm) | 6.2 | Connector cross section (fixed)(mm²) | 0.14 - 6 | Connector cross-section (flexible)(mm²) | 0.14 - 6 |
|---|---|---|---|---|---|
| Nominal voltage(V) | 500 | Nominal current(A) | 6.3 | No. of rows | 1 |
| Product size (height)(mm) | 73 | Product size (length)(mm) | 57.8 | Flammability rating | V0 |
| Connection (components) | Screws |
Configure
Basic Attributes
-
Total number of pins(Pole)
-
Color
- Black
- Blue
- Grey
-
AWG
-
Nominal current (details)(A)
-
Product size (width)(mm)
-
Stripping length(mm)
-
Connector type (category)
- Fuse box feed-trough terminal
- Fuse serial terminal
-
Insulation material
- PA
-
Industrial goods
- No
Filter by standard shipping days
-
- All
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
