Gauge-separator terminal PTT 2,5-2MT
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
3210265
Basic information
| Total number of pins(Pole) | 2 | Color | Blue | Clamp width(mm) | 5.2 |
|---|---|---|---|---|---|
| Connector cross section (fixed)(mm²) | 0.14 - 2.50 | Connector cross-section (flexible)(mm²) | 0.14 - 2.50 | Nominal voltage(V) | 400 |
| Nominal current(A) | 16 | No. of rows | 2 | Product size (height)(mm) | 47.4 |
| Flammability rating | V0 | Connection (components) | Push-in connector | Connector type (category) | Disconnect terminal |
| Industrial goods | Yes |
This page is Gauge-separator terminal PTT 2,5-2MT, part number 3210265.
You can find the detail information about specifications and dimensions on part number 3210265.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
