Feed-through terminal block UT 4-FE
Product Details:
Manufacturer part number: 3047617
Brand: PHOENIX CONTACT
Price: 1.25 €
Delivery time: 7 Days
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
3047617
Basic information
| Total number of pins(Pole) | 2 | Color | Black-yellow | AWG | 26 - 10 |
|---|---|---|---|---|---|
| Clamp width(mm) | 6.2 | Connector cross section (fixed)(mm²) | 0.14 - 6 | Connector cross-section (flexible)(mm²) | 0.14 - 6 |
| Nominal voltage(V) | 1000 | Nominal current(A) | 41 | No. of rows | 1 |
| Product size (height)(mm) | 47.5 | Product size (length)(mm) | 46.9 | Product size (width)(mm) | 6.2 |
| Stripping length(mm) | 9(max.) | Connection (components) | Screws | Connector type (category) | Continuity |
| Industrial goods | Yes |
This page is Feed-through terminal block UT 4-FE, part number 3047617.
You can find the detail information about specifications and dimensions on part number 3047617.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
