Bus system cable SAC-5P, Plug straight M12, B-coded, Socket straight M12, B-coded
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Loading...
Basic information
| Connection side A (sensors/actuators) | socket, straight | Connection side B (sensors/actuators) | socket, straight | Connector cross-section (max.)(mm²) | 0.22 |
|---|---|---|---|---|---|
| Temperature range(°C) | -40 - +105 | Number of pins | 5 | Nominal current(A) | 4 |
| Nominal voltage(V AC) | 48 | IP rating | IP67 | Thread type connection side | M12 |
| Coding | B | Cable colour | Violet | Connector standard | Bus connector |
| Connector type | Socket, straight | Jacket material | PUR | Seal type | Screw-on |
| Sensor/actuator cable features | Shielded | Sensor/actuator wiring type (category) | Sensor/actuator data cable (pre-fab) |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
