Relay module RIF-0-OSC
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
2905657
Basic information
| Product size (height)(mm) | 84 | Product size (width)(mm) | 6.2 | Product size (depth)(mm) | 68 |
|---|---|---|---|---|---|
| Current load (max.)(mA) | 3 | Control voltage range | 19.2 - 28.8 Vdc | Nominal voltage(Vdc) | 24 |
| Switching voltage (max.)(Vdc) | 33 | Switching voltage (min.)(Vdc) | 3 | Max. temperature(°C) | +60 |
| Min. temperature(°C) | -25 | Contact type | 1 maker | Connection (components) | Screw terminal |
| Relay type (category) | SSR | Industrial goods | Yes |
This page is Relay module RIF-0-OSC, part number 2905657.
You can find the detail information about specifications and dimensions on part number 2905657.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
