Traction contactor, AC-3 185 A
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 3RT10562XB460LA2 |
| 3RT10562XF460LA2 |
| 3RT10562XJ460LA2 |
| 3RT10566XB460LA2 |
| 3RT10566XF460LA2 |
| 3RT10566XJ460LA2 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | |
|---|---|---|---|---|
1,492.13 € | 1 | Available | 4 Days | |
1,503.07 € | 1 | Available | 4 Days | |
1,481.21 € | 1 | Available | 4 Days | |
1,485.57 € | 1 | Available | 4 Days | |
1,485.57 € | 1 | Available | Quote | |
1,492.13 € | 1 | Available | Quote |
Loading...
Basic information
| No. of pins | 3-pin | Product size (height)(mm) | 172 | Product size (width)(mm) | 120 |
|---|---|---|---|---|---|
| Durability | 10000000 | Nominal voltage(V AC) | 1000 | Frame size | S6 |
| Contact type | 3 makers | Auxiliary contact type | 2 makers, 2 breakers | Connection (components) | Screw terminals |
| Mounting type (relays) | Screw-fit |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
