Contactor, AC-1: 160 A
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 3RT24481AB00 |
| 3RT24481AF00 |
| 3RT24481AK60 |
| 3RT24481AL20 |
| 3RT24481AP00 |
| 3RT24481AP60 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Connection (components) | |
|---|---|---|---|---|---|
490.83 € | 1 | Available | 4 Days | Clamp | |
490.83 € | 1 | Available | Quote | - | |
490.83 € | 1 | Available | 4 Days | - | |
486.44 € | 1 | Available | 4 Days | Clamp | |
490.83 € | 1 | Available | 4 Days | - | |
490.83 € | 1 | Available | 4 Days | Clamp |
Loading...
Basic information
| No. of pins | 3-pin | Product size (height)(mm) | 140 | Product size (width)(mm) | 70 |
|---|---|---|---|---|---|
| Product size (depth)(mm) | 152 | Durability | 10000000 | Min. temperature(°C) | -25 |
| Max. temperature(°C) | +60 | Frame size | S3 | IP rating | IP20 |
| Contact type | 3 makers | Auxiliary contact type | 1 maker, 1 breaker | Mounting type (relays) | Snap-in, Screw-fit |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
