Circuit breaker 3VA6 UL frame 400 breaking capacity class C
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Number of pins | Product size (width) (mm) | Adjustment range (amperage) | OCR type | |
|---|---|---|---|---|---|---|---|---|
2,414.56 € | 1 | 4 Days | 4-pin | 184 | 100 - 250 A | ETU320 | ||
2,777.59 € | 1 | 4 Days | 4-pin | 184 | 100 - 250 A | ETU320 | ||
1,982.07 € | 1 | 98 Days | 3-pin | 138 | 100 - 250 A | ETU350 | ||
2,705.88 € | 1 | 98 Days | 4-pin | 184 | 100 - 250 A | ETU350 | ||
2,907.56 € | 1 | 4 Days | 4-pin | 184 | 100 - 250 A | ETU350 | ||
2,519.89 € | 1 | 98 Days | 3-pin | 138 | 100 - 250 A | ETU550 | ||
2,784.32 € | 1 | 98 Days | 3-pin | 138 | 100 - 250 A | ETU550 | ||
3,467.79 € | 1 | 4 Days | 4-pin | 184 | 100 - 250 A | ETU550 | ||
2,840.33 € | 1 | 98 Days | 3-pin | 138 | 100 - 250 A | ETU560 | ||
3,120.45 € | 1 | 4 Days | 3-pin | 138 | 100 - 250 A | ETU560 | ||
2,515.40 € | 1 | 4 Days | 3-pin | 138 | 100 - 250 A | ETU556 | ||
3,120.45 € | 1 | 4 Days | 3-pin | 138 | 100 - 250 A | ETU556 | ||
3,803.92 € | 1 | 4 Days | 4-pin | 184 | 100 - 250 A | ETU556 | ||
2,929.97 € | 1 | 4 Days | 3-pin | 138 | 100 - 250 A | ETU820 | ||
3,606.72 € | 1 | 4 Days | 4-pin | 184 | 100 - 250 A | ETU820 | ||
2,923.25 € | 1 | 4 Days | 3-pin | 138 | 100 - 250 A | ETU830 | ||
2,638.65 € | 1 | 98 Days | 3-pin | 138 | 100 - 250 A | ETU850 | ||
3,243.69 € | 1 | 4 Days | 3-pin | 138 | 100 - 250 A | ETU860 | ||
3,573.11 € | 1 | 4 Days | 4-pin | 184 | 100 - 250 A | ETU860 | ||
3,938.37 € | 1 | 4 Days | 4-pin | 184 | 100 - 250 A | ETU860 | ||
2,795.52 € | 1 | 98 Days | 3-pin | 138 | 100 - 250 A | ETU856 | ||
3,243.69 € | 1 | 4 Days | 3-pin | 138 | 100 - 250 A | ETU856 | ||
2,324.93 € | 1 | 98 Days | 3-pin | 138 | 160 - 400 A | ETU330 | ||
2,929.97 € | 1 | 4 Days | 4-pin | 184 | 160 - 400 A | ETU330 | ||
2,127.73 € | 1 | 12 Days | 3-pin | 138 | 160 - 400 A | ETU350 | ||
3,371.43 € | 1 | 98 Days | 4-pin | 184 | 160 - 400 A | ETU550 | ||
2,918.77 € | 1 | 98 Days | 3-pin | 138 | 160 - 400 A | ETU560 | ||
2,515.40 € | 1 | 98 Days | 3-pin | 138 | 160 - 400 A | ETU556 | ||
3,449.85 € | 1 | 4 Days | 4-pin | 184 | 160 - 400 A | ETU820 | ||
2,923.25 € | 1 | 4 Days | 3-pin | 138 | 160 - 400 A | ETU830 | ||
3,535.01 € | 1 | 4 Days | 4-pin | 184 | 160 - 400 A | ETU830 | ||
3,568.63 € | 1 | 4 Days | 4-pin | 184 | 160 - 400 A | ETU850 | ||
3,053.23 € | 1 | 98 Days | 3-pin | 138 | 160 - 400 A | ETU860 | ||
2,795.52 € | 1 | 98 Days | 3-pin | 138 | 160 - 400 A | ETU856 | ||
3,393.84 € | 1 | 4 Days | 4-pin | 184 | 160 - 400 A | ETU856 |
Loading...
Basic information
| Mounting type (relays) | Fixed | Product size (height)(mm) | 248 | Product size (depth)(mm) | 110 |
|---|---|---|---|---|---|
| Min. temperature(°C) | -25 | Max. temperature(°C) | +70 | Switching voltage (max.)(V DC/AC) | 600 |
| IP rating | IP40 | Breaking capacity rating | C |
