Current monitoring relays, 3 - 30 mA, 10 - 100 mA, 0.1 - 1 A, 24 - 240 V AC, 50 / 60 Hz, 24 - 240 V DC
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
EMR6-IF1-A-1
Basic information
| Width(mm) | 22.5 | Height(mm) | 85.6 | Depth(mm) | 104.6 |
|---|---|---|---|---|---|
| Current measurement range(A) | 0.01|1 | External current transformer | - | With detachable clamps | false |
| Single-phase hysteresis possible | true | Three-phase hysteresis possible | false | Single-phase under current possible | true |
| Three-phase under current possible | false | Single-phase over current possible | true | Three-phase over current possible | false |
| Contains function DC-voltage under current | true | Contains function DC-voltage over current | true | Function DC-current hysteresis | true |
| Type of electric connection | Screw connection | Rated control supply voltage Us at AC 50HZ(V) | 24|240 | Rated control supply voltage Us at AC 60HZ(V) | 24|240 |
| Rated control supply voltage Us at DC(V) | 24|240 | Max. permitted delay-on energization time(s) | 30 | Min. adjustable delay-on energization time(s) | 0.1 |
| Max. permitted off-delay time(s) | 30 | Min. adjustable off-delay time(s) | 0.1 | Voltage type for actuating | AC/DC |
| Number of contacts as normally closed contact | 0 | Number of contacts as normally open contact | 0 | Number of contacts as change-over contact | 2 |
This page is Current monitoring relays, 3 - 30 mA, 10 - 100 mA, 0.1 - 1 A, 24 - 240 V AC, 50 / 60 Hz, 24 - 240 V DC, part number EMR6-IF1-A-1.
You can find the detail information about specifications and dimensions on part number EMR6-IF1-A-1.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
