SWD I / O module
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| EU5E-SWD-2A2A |
| EU5E-SWD-4D2R |
| EU5E-SWD-4D4D |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Input current at signal 1 (mA) | Number of digital inputs | Number of digital outputs | Number of analogue inputs | Number of analogue outputs | Time delay at signal exchange (ms) | With optical interface | Type of voltage (input voltage) | Output current (A) | Short-circuit protection, outputs available | Input, current | Input, voltage | Input, resistor | Input, resistance thermometer | Input, thermocouple | Input signal, configurable | Output, current | Output, voltage | Output signal configurable | Resolution of the analogue inputs (Bit) | Resolution of the analogue outputs (Bit) | Type of digital output | Type of electric connection | Category according to EN 954-1 | Supply voltage DC (V) | Permitted voltage at output (V) | Permitted voltage at input (V) | Type of output voltage | Digital inputs configurable | Analogue inputs configurable | Analogue outputs configurable | Digital outputs configurable | Degree of protection (NEMA) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
356.94 € | 1 | 3 Days | - | - | - | 2 | 2 | - | - | - | - | - | true | true | false | false | false | false | true | true | true | 12 | 12 | - | Flat plug-in connection | - | 0|0 | - | - | - | - | true | true | - | - | |||
113.20 € | 1 | 3 Days | 4 | 4 | 2 | - | - | 0|0 | false | DC | 3 | false | - | - | - | - | - | - | - | - | - | - | - | Relay | Other | None | 0|28.8 | 0|250 | 20.4|28.8 | AC | false | - | - | false | - | |||
118.12 € | 1 | 3 Days | 4 | 4 | 4 | - | - | 0|0 | false | DC | 0.5 | false | - | - | - | - | - | - | - | - | - | - | - | Other | Other | None | 20.4|28.8 | 20.4|28.8 | 20.4|28.8 | DC | false | - | - | false | - |
Loading...
Basic information
| Supporting protocol for AS-Interface Safety at Work | false | Fieldbus connection over separate bus coupler possible | true | Width(mm) | 35 |
|---|---|---|---|---|---|
| Height(mm) | 90 | Depth(mm) | 97 | Suitable for safety functions | false |
| Voltage type of supply voltage | DC | Supporting protocol for LON | false | Number of HW-interfaces industrial Ethernet | 0 |
| Number of HW-interfaces RS-232 | 0 | Number of HW-interfaces RS-422 | 0 | Number of HW-interfaces RS-485 | 0 |
| Number of HW-interfaces serial TTY | 0 | Number of HW-interfaces USB | 0 | Number of HW-interfaces parallel | 0 |
| Number of HW-interfaces other | 0 | Supporting protocol for TCP/IP | false | Supporting protocol for ASI | false |
| Supporting protocol for PROFIBUS | false | Supporting protocol for CAN | false | Supporting protocol for INTERBUS | false |
| Supporting protocol for KNX | false | Supporting protocol for MODBUS | false | Supporting protocol for Data-Highway | false |
| Supporting protocol for DeviceNet | false | Supporting protocol for SUCONET | false | Supporting protocol for other bus systems | true |
| Rail mounting possible | true | Explosion safety category for gas | None | Explosion safety category for dust | None |
| System accessory | true | Appendant operation agent (Ex ia) | false | Appendant operation agent (Ex ib) | false |
| Degree of protection (IP) | IP20 | Supporting protocol for SERCOS | false | Supporting protocol for INTERBUS-Safety | false |
| Number of interfaces PROFINET | 0 | Number of HW-interfaces Wireless | 0 | Front build in possible | false |
| Rack-assembly possible | false | Wall mounting/direct mounting | true | Radio standard Bluetooth | false |
| Radio standard WLAN 802.11 | false | IO link master | false | Performance level acc. EN ISO 13849-1 | None |
| Supporting protocol for DeviceNet Safety | false | Supporting protocol for EtherNet/IP | false | Supporting protocol for Foundation Fieldbus | false |
| Supporting protocol for PROFINET CBA | false | Supporting protocol for PROFINET IO | false | Supporting protocol for PROFIsafe | false |
| Supporting protocol for SafetyBUS p | false | Supply voltage AC 50 Hz(V) | 0|0 | Supply voltage AC 60 Hz(V) | 0|0 |
| Radio standard GPRS | false | Radio standard GSM | false | Radio standard UMTS | false |
| SIL according to IEC 61508 | None |
Configure
Basic Attributes
-
Input current at signal 1(mA)
-
Number of digital inputs
-
Number of digital outputs
-
Number of analogue inputs
-
Number of analogue outputs
-
Time delay at signal exchange(ms)
-
With optical interface
-
Type of voltage (input voltage)
-
Output current(A)
-
Short-circuit protection, outputs available
-
Input, current
-
Input, voltage
-
Input, resistor
-
Input, resistance thermometer
-
Input, thermocouple
-
Input signal, configurable
-
Output, current
-
Output, voltage
-
Output signal configurable
-
Resolution of the analogue inputs(Bit)
-
Resolution of the analogue outputs(Bit)
-
Type of digital output
-
Type of electric connection
-
Category according to EN 954-1
-
Supply voltage DC(V)
-
Permitted voltage at output(V)
-
Permitted voltage at input(V)
-
Type of output voltage
-
Digital inputs configurable
-
Analogue inputs configurable
-
Analogue outputs configurable
-
Digital outputs configurable
-
Degree of protection (NEMA)
-
Type
Filter by standard shipping days
-
- All
- 3 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
