Circuit-breaker, 3p, 100A, motor protection
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
NZMH1-M100
Basic information
| Rated short-circuit breaking capacity lcu at 400 V, AC(kA) | 100 | Width(mm) | 90 | Height(mm) | 145 |
|---|---|---|---|---|---|
| Depth(mm) | 88 | Rated operation power at AC-3, 400 V(kW) | 55 | With integrated auxiliary switch | false |
| Rated permanent current Iu(A) | 100 | With integrated under voltage release | false | Number of poles | 3 |
| Rated operating voltage(V) | 690|690 | Overload release current setting(A) | 80|100 | Degree of protection (IP) | IP20 |
| With thermal protection | true | Type of electrical connection of main circuit | Other | Type of control element | Rocker lever |
| Switch off technique | Thermomagnetic | Rated operation power at AC-3, 230 V(kW) | 30 | Phase failure sensitive | true |
| Device construction | Built-in device fixed built-in technique | Adjustment range undelayed short-circuit release(A) | 800|1250 |
This page is Circuit-breaker, 3p, 100A, motor protection, part number NZMH1-M100.
You can find the detail information about specifications and dimensions on part number NZMH1-M100.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
