Series connection time switch
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| TSQD1CO |
| TSQD1NO |
| TSSD1CO |
| TSSD1NO |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Width (mm) | Depth (mm) | Contact type | Width in number of modular spacings | Mains synchronous | Quartz controlled | Switching preselection | Voltage type of supply voltage | Supply voltage (V) | Frequency supply voltage (Hz) | Autonomy in hours | Accuracy per day (s) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
133.00 € | 1 | 3 Days | 54 | 65.6 | Change-over contact | 3 | false | true | true | AC | 110|230 | 45|60 | 200 | 1 | |||
117.00 € | 1 | 3 Days | 17.5 | 65.5 | Normally open contact | 1 | false | true | false | AC/DC | 230|240 | 45|60 | 72 | 1 | |||
103.00 € | 1 | 3 Days | 54 | 65.6 | Change-over contact | 3 | true | false | true | AC | 230|230 | 50|50 | 0 | 0 | |||
95.50 € | 1 | 3 Days | 17.5 | 65.5 | Normally open contact | 1 | true | true | true | AC | 230|230 | 50|50 | 0 | 0 |
Loading...
Basic information
| Mounting method | DIN rail | Height(mm) | 90 | Number of channels | 1 |
|---|---|---|---|---|---|
| Weekly program | false | Annual program | false | 60 min. program | false |
| 24 h program | true | Automatic switching summer-/winter time | false | Manual operation | true |
| Potential free switch contact | true | Autonomy in years | 0 | Shortest switching time channel 1(min) | 15 |
| Shortest switching time channel 2(min) | 0 | Nominal switching current at 250 V AC(A) | 16 | Program shift divide 1(min) | 15 |
| Program shift divide 2(min) | 0 | Degree of protection (IP) | IP20 |
Configure
Basic Attributes
-
Width(mm)
-
Depth(mm)
-
Contact type
-
Width in number of modular spacings
-
Mains synchronous
-
Quartz controlled
-
Switching preselection
-
Voltage type of supply voltage
-
Supply voltage(V)
-
Frequency supply voltage(Hz)
-
Autonomy in hours
-
Accuracy per day(s)
-
Type
Filter by standard shipping days
-
- All
- 3 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
