Crimp Cable Lug + Peephole 180 °
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 91R3 |
| 91R4 |
| 92R3 |
| 92R4 |
| 92R5 |
| 93R4 |
| 93R5 |
| 93R6 |
| 94R5 |
| 94R6 |
| 94R8 |
| 95R5 |
| 95R6 |
| 95R8 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Cross section (mm²) | Cross section (max.) (mm²) | Hole Ø (mm) | Manufacturer part # | Thread size | Type (manufacturer type) | |
|---|---|---|---|---|---|---|---|---|---|---|
0.32 € | 1 | Available | 3 Days | 0.75 | 0.705 | 3.2 | 91R3 | M3 | 91R3 | |
0.32 € | 1 | Available | 3 Days | 0.75 | 0.705 | 4.3 | 91R4 | M4 | 91R4 | |
0.33 € | 1 | Available | 3 Days | 1.5 | 1.5 | 3.2 | 92R3 | M3 | 92R3 | |
0.33 € | 1 | Available | 3 Days | 1.5 | 1.5 | 4.3 | 92R4 | M4 | 92R4 | |
0.31 € | 1 | Available | 3 Days | - | 1.5 | 5.3 | 92R5 | M5 | 92R5 | |
0.43 € | 1 | Available | 3 Days | 2.5 | 2.5 | 4.3 | 93R4 | M4 | 93R4 | |
0.43 € | 1 | Available | 3 Days | 2.5 | 2.5 | 5.3 | 93R5 | M5 | 93R5 | |
0.44 € | 1 | Available | 3 Days | 2.5 | 2.5 | 6.5 | 93R6 | M6 | 93R6 | |
0.51 € | 1 | Available | 3 Days | 4 | 4 | 5.3 | 94R5 | M5 | 94R5 | |
0.67 € | 1 | Available | 3 Days | - | 4 | 6.5 | 94R6 | M6 | 94R6 | |
0.80 € | 1 | Available | 3 Days | 4 | 4 | 8.5 | 94R8 | M8 | 94R8 | |
0.65 € | 1 | Available | 3 Days | - | 6 | 5.3 | 95R5 | M5 | 95R5 | |
0.60 € | 1 | Available | 3 Days | 6 | 6 | 6.5 | 95R6 | M6 | 95R6 | |
0.76 € | 1 | Available | 3 Days | 6 | 6 | 8.5 | 95R8 | M8 | 95R8 |
Loading...
Basic information
| Connection angle(°) | 180 | Connector features | + peephole | Contact material | Copper silver plated |
|---|---|---|---|---|---|
| Material (details) | Cu. tin-plated surface | Product type | Crimp cable lug | Type (misc.) | With inspection hole. for fine-stranded conductors |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
