Isolation Cap Sideways Open
- Volume Discount
[Specifications]
・Product type: Insulated grommet
・Case features: open-sided
・Material: Polyamide
・Colour: Black
・Board thickness (max.)(mm): 3.2
Suitable for holes with prior attached cables and for cables with prior attached connectors. The mentioned hole diameter has to be considered as a nominal dimension, montage in slightly bigger holes is possible.
・Product type: Insulated grommet
・Case features: open-sided
・Material: Polyamide
・Colour: Black
・Board thickness (max.)(mm): 3.2
Suitable for holes with prior attached cables and for cables with prior attached connectors. The mentioned hole diameter has to be considered as a nominal dimension, montage in slightly bigger holes is possible.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| H-2867 |
| H-2869 |
| H-2871 |
| H-2873 |
| H-2874 |
| H-2878 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Manufacturer part # | Mounting hole | Product size (Ø) (mm) | Terminal Ø (max.) (mm) | Type (manufacturer type) | |
|---|---|---|---|---|---|---|---|---|---|
0.24 € | 1 | Available | 3 Days | H-2867 | 11.1 mm | 23.4 | 17.1 | H-2867 | |
0.24 € | 1 | Available | 3 Days | H-2869 | 14.3 mm | 20.2 | 13.9 | H-2869 | |
0.20 € | 1 | Available | 3 Days | H-2871 | 12.7 mm | 14.3 | 7.9 | H-2871 | |
0.36 € | 1 | Available | 3 Days | H-2873 | 19 mm | 16.3 | 9.9 | H-2873 | |
0.55 € | 1 | Available | 3 Days | H-2874 | 22.2 mm | 12.3 | 7.9 | H-2874 | |
0.60 € | 1 | Available | 3 Days | H-2878 | 25.4 mm | 10.3 | 20.2 | H-2878 |
Loading...
Basic information
| Board thickness (max.)(mm) | 3.2 | Case features | open-sided | Colour | Black |
|---|---|---|---|---|---|
| Halogen-free | No | Material | Polyamide | Max. temperature(°C) | +105 |
| Min. temperature(°C) | -30 | Product size (height)(mm) | 10.3 | Product type | Insulated grommet |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
