Configure

AWG max.
- 10
- 12
- 14
- 16
- 22
AWG (min.)
- 10
- 12
- 14
- 16
- 22
Colour
Connector features
- + branch joint
Connector thickness(mm)
- 0.5
- 0.8
Connector width(mm)
- 2.8
- 4.8
- 6.30
- 6.35
- 6.4
- 8
- 9.50
Cross-section range
Cross section (max.)(mm²)
- 1.5
- 2.5
- 6
Industrial goods
- No
Insulation type
- Insulated
- Partially insulated
Manufacturer part #
- 737443
- 737554
- 737623
- 737662
- 737698
- 737792
- 737840
- 745086
- 745098
- 745110
- 745122
- 745136
- 745151
- 745166
- 745180
- 745194
- 745208
- 1582963
- 1582964
- 1582965
- 1582966
- 1582969
- 1582970
- 1582971
- 1582972
- 1582973
- 1582974
- 1583061
- 1583078
- 1583079
- 1583080
- 1583081
- 1583082
- 1583083
- 1583084
- 1583085
- 1583086
- 1583087
- 1583088
- 1583090
- 1583091
- 1583092
Min. cross section(mm²)
- 0.5
- 1.5
- 4
Size
Support sleeve
- No
- Yes
Temperature range(°C)
- Up to +70
Type (manufacturer type)
- FDD1.25-250
- FDD1.25-187(5)
- FDFD1.25-187(5)
- FDD1.25-187(8)
- FDFD1.25-187(8)
- FDD1.25-110(5)
- FDFD1.25-110(5)
- FDD1.25-110(8)
- FDD2-250
- FDD2-187 (5)
- FDFD 2-187 (5)
- FDD2-187(8)
- FDFD 2-187 (8)
- FDD2-110(8)
- FDD5.5-250
- FDFD5.5-250
- FDD 5.5-187
- 1582963
- 1582964
- 1582965
- 1582966
- 1582969
- 1582970
- 1582971
- 1582972
- 1582973
- 1582974
- 1583061
- 1583078
- 1583079
- 1583080
- 1583081
- 1583082
- 1583083
- 1583084
- 1583085
- 1583086
- 1583087
- 1583088
- 1583090
- 1583091
- 1583092
Est. shipping days
- All
- Within 3 working days
- Within 13 working days
- Within 16 working days

Blade receptacle【1 to 100 pieces】

Catalog

Part number:

Still undefined. 42 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

AWG max.

AWG (min.)

Colour

Connector features

Connector thickness

(mm)

Connector width

(mm)

Cross-section range

Cross section (max.)

(mm²)

Industrial goods

Insulation type

Manufacturer part #

Min. cross section

(mm²)

Size

Support sleeve

Temperature range

(°C)

Type (manufacturer type)

Minimum order quantity

12	10	Yellow	-	0.8	6.4	4 - 6 mm²	6	-	Insulated	745086	4	6.4 x 0.8 mm	No	Up to +70	FDFD5.5-250	1 packs 50 pieces
22	16	Red	-	0.8	2.8	0.50 - 1.50 mm²	1.5	-	Partially insulated	745110	0.5	2.8 x 0.8 mm	No	Up to +70	FDD1.25-110(8)	1 packs 100 pieces
16	14	Blue	-	0.5	4.8	1.50 - 2.50 mm²	2.5	-	Partially insulated	745166	1.5	4.8 x 0.5 mm	No	Up to +70	FDD2-187 (5)	1 packs 100 pieces
12	10	Yellow	-	0.8	6.4	4 - 6 mm²	6	-	Partially insulated	745208	4	6.4 x 0.8 mm	No	Up to +70	FDD5.5-250	1 packs 50 pieces
12	10	Yellow	-	0.5	4.8	4 - 6 mm²	6	-	Partially insulated	737554	4	4.8 x 0.5 mm	No	Up to +70	FDD 5.5-187	1 packs 50 pieces
14	16	Blue	-	0.8	6.30	1.50 - 2.50 mm²	2.5	No	Partially insulated	1582963	1.5	6.30 x 0.80 mm	Yes	-	1582963	1 pieces
14	16	Blue	-	0.8	8	1.50 - 2.50 mm²	2.5	No	Partially insulated	1582964	1.5	8 x 0.80 mm	Yes	-	1582964	1 pieces
16	22	Red	-	0.8	2.8	0.50 - 1.50 mm²	1.5	-	Insulated	1582965	0.5	2.80 x 0.80 mm	Yes	-	1582965	1 pieces
14	16	Blue	-	0.5	2.8	1.50 - 2.50 mm²	2.5	-	Insulated	1582966	1.5	2.80 x 0.50 mm	Yes	-	1582966	1 pieces
16	22	Red	-	0.5	2.8	0.50 - 1.50 mm²	1.5	No	Partially insulated	1582969	0.5	2.80 x 0.50 mm	Yes	-	1582969	1 pieces
14	16	Blue	-	0.5	4.8	1.50 - 2.50 mm²	2.5	No	Partially insulated	1582970	1.5	4.80 x 0.50 mm	Yes	-	1582970	1 pieces
16	22	Red	-	0.5	4.8	0.50 - 1.50 mm²	1.5	-	Insulated	1582971	0.5	4.80 x 0.50 mm	Yes	-	1582971	1 pieces
14	16	Blue	-	0.8	6.30	1.50 - 2.50 mm²	2.5	-	Insulated	1582972	1.5	6.30 x 0.80 mm	Yes	-	1582972	1 pieces
14	16	Blue	+ branch joint	0.8	6.30	1.50 - 2.50 mm²	2.5	-	Partially insulated	1582973	1.5	6.30 x 0.80 mm	Yes	-	1582973	1 pieces
10	12	Yellow	+ branch joint	0.8	6.30	4 - 6 mm²	6	-	Partially insulated	1582974	4	6.30 x 0.80 mm	Yes	-	1582974	1 pieces
16	22	Red	-	0.8	4.8	0.50 - 1.50 mm²	1.5	No	Partially insulated	1583061	0.5	4.80 x 0.80 mm	Yes	-	1583061	1 pieces
16	22	Red	-	0.8	2.8	0.50 - 1.50 mm²	1.5	No	Partially insulated	1583078	0.5	2.80 x 0.80 mm	Yes	-	1583078	1 pieces
16	22	Red	-	0.5	4.8	0.50 - 1.50 mm²	1.5	No	Partially insulated	1583079	0.5	4.80 x 0.50 mm	Yes	-	1583079	1 pieces
16	22	Red	-	0.8	6.30	0.50 - 1.50 mm²	1.5	No	Partially insulated	1583080	0.5	6.30 x 0.80 mm	Yes	-	1583080	1 pieces
14	16	Blue	-	0.5	2.8	1.50 - 2.50 mm²	2.5	No	Partially insulated	1583081	1.5	2.80 x 0.50 mm	Yes	-	1583081	1 pieces
14	16	Blue	-	0.8	2.8	1.50 - 2.50 mm²	2.5	No	Partially insulated	1583082	1.5	2.80 x 0.80 mm	Yes	-	1583082	1 pieces
14	16	Blue	-	0.8	4.8	1.50 - 2.50 mm²	2.5	No	Partially insulated	1583083	1.5	4.80 x 0.80 mm	Yes	-	1583083	1 pieces
10	12	Yellow	-	0.8	6.30	4 - 6 mm²	6	No	Partially insulated	1583084	4	6.30 x 0.80 mm	Yes	-	1583084	1 pieces
10	12	Yellow	-	0.8	9.50	4 - 6 mm²	6	No	Partially insulated	1583085	4	9.50 x 0.80 mm	Yes	-	1583085	1 pieces
16	22	Red	-	0.5	2.8	0.50 - 1.50 mm²	1.5	-	Insulated	1583086	0.5	2.80 x 0.50 mm	Yes	-	1583086	1 pieces
16	22	Red	-	0.8	4.8	0.50 - 1.50 mm²	1.5	-	Insulated	1583087	0.5	4.80 x 0.80 mm	Yes	-	1583087	1 pieces
16	22	Red	-	0.8	6.30	0.50 - 1.50 mm²	1.5	-	Insulated	1583088	0.5	6.30 x 0.80 mm	Yes	-	1583088	1 pieces
14	16	Blue	-	0.8	4.8	1.50 - 2.50 mm²	2.5	-	Insulated	1583090	1.5	4.80 x 0.80 mm	Yes	-	1583090	1 pieces
10	12	Yellow	-	0.8	6.30	4 - 6 mm²	6	-	Insulated	1583091	4	6.30 x 0.80 mm	Yes	-	1583091	1 pieces
16	22	Red	+ branch joint	0.8	6.30	0.50 - 1.50 mm²	1.5	-	Partially insulated	1583092	0.5	6.30 x 0.80 mm	Yes	-	1583092	1 pieces
16	14	Blue	-	0.8	2.8	1.50 - 2.50 mm²	2.5	-	Partially insulated	737443	1.5	2.8 x 0.8 mm	No	Up to +70	FDD2-110(8)	1 packs 100 pieces
22	16	Red	-	0.5	2.8	0.50 - 1.50 mm²	1.5	-	Insulated	737623	0.5	2.8 x 0.5 mm	No	Up to +70	FDFD1.25-110(5)	1 packs 50 pieces
22	16	Red	-	0.5	4.8	0.50 - 1.50 mm²	1.5	-	Insulated	737662	0.5	4.8 x 0.5 mm	No	Up to +70	FDFD1.25-187(5)	1 packs 50 pieces
22	16	Red	-	0.8	6.35	0.50 - 1.50 mm²	1.5	-	Insulated	737698	0.5	6.35 x 0.8 mm	No	Up to +70	FDFD1.25-187(8)	1 packs 50 pieces
16	14	Blue	-	0.5	4.8	1.50 - 2.50 mm²	2.5	-	Insulated	737792	1.5	4.8 x 0.5 mm	No	Up to +70	FDFD 2-187 (5)	1 packs 50 pieces
16	14	Blue	-	0.8	6.35	1.50 - 2.50 mm²	2.5	-	Insulated	737840	1.5	6.35 x 0.8 mm	No	Up to +70	FDFD 2-187 (8)	1 packs 50 pieces
22	16	Red	-	0.5	2.8	0.50 - 1.50 mm²	1.5	-	Partially insulated	745098	0.5	2.8 x 0.5 mm	No	Up to +70	FDD1.25-110(5)	1 packs 100 pieces
22	16	Red	-	0.5	4.8	0.50 - 1.50 mm²	1.5	-	Partially insulated	745122	0.5	4.8 x 0.5 mm	No	Up to +70	FDD1.25-187(5)	1 packs 100 pieces
22	16	Red	-	0.8	4.8	0.50 - 1.50 mm²	1.5	-	Partially insulated	745136	0.5	4.8 x 0.8 mm	No	Up to +70	FDD1.25-187(8)	1 packs 100 pieces
22	16	Red	-	0.5	6.4	0.50 - 1.50 mm²	1.5	-	Partially insulated	745151	0.5	6.4 x 0.5 mm	No	Up to +70	FDD1.25-250	1 packs 100 pieces
16	14	Blue	-	0.8	4.8	1.50 - 2.50 mm²	2.5	-	Partially insulated	745180	1.5	4.8 x 0.8 mm	No	Up to +70	FDD2-187(8)	1 packs 100 pieces
16	14	Blue	-	0.8	6.4	1.50 - 2.50 mm²	2.5	-	Partially insulated	745194	1.5	6.4 x 0.8 mm	No	Up to +70	FDD2-250	1 packs 100 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

7.88 € ( 9.38 € )	3 working days
6.84 € ( 8.14 € )	3 working days
7.88 € ( 9.38 € )	3 working days
6.84 € ( 8.14 € )	16 working days
7.35 € ( 8.75 € )	3 working days
0.12 € ( 0.14 € )	3 working days
0.19 € ( 0.23 € )	3 working days
0.13 € ( 0.15 € )	3 working days
0.17 € ( 0.20 € )	3 working days
0.11 € ( 0.13 € )	3 working days
0.13 € ( 0.15 € )	3 working days
0.13 € ( 0.15 € )	3 working days
0.17 € ( 0.20 € )	3 working days
0.17 € ( 0.20 € )	3 working days
0.25 € ( 0.30 € )	3 working days
0.12 € ( 0.14 € )	3 working days
0.11 € ( 0.13 € )	16 working days
0.12 € ( 0.14 € )	3 working days
0.11 € ( 0.13 € )	3 working days
0.13 € ( 0.15 € )	3 working days
0.11 € ( 0.13 € )	3 working days
0.13 € ( 0.15 € )	3 working days
0.25 € ( 0.30 € )	3 working days
0.28 € ( 0.33 € )	3 working days
0.13 € ( 0.15 € )	13 working days
0.13 € ( 0.15 € )	3 working days
0.17 € ( 0.20 € )	3 working days
0.15 € ( 0.18 € )	3 working days
0.24 € ( 0.29 € )	3 working days
0.17 € ( 0.20 € )	3 working days
7.88 € ( 9.38 € )	3 working days
7.35 € ( 8.75 € )	3 working days
7.35 € ( 8.75 € )	3 working days
7.88 € ( 9.38 € )	3 working days
7.35 € ( 8.75 € )	3 working days
7.35 € ( 8.75 € )	3 working days
7.35 € ( 8.75 € )	3 working days
7.35 € ( 8.75 € )	3 working days
7.35 € ( 8.75 € )	3 working days
6.84 € ( 8.14 € )	3 working days
7.35 € ( 8.75 € )	3 working days
7.88 € ( 9.38 € )	3 working days
