Laser module Dot
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1566747 |
| 1571396 |
| 1572138 |
| 1572168 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Colour | Product size (length) (mm) | Focus properties | Laser category | Operating current (mA) | Power (mW) | Product size (Ø) (mm) | Type | Wavelength (nm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
35.36 € | 1 | Available | 3 Days | Green | 50 | - | 2 | 240 | 1 | 14 | LM01GND | 532 | |
34.28 € | 1 | Available | 3 Days | Green | 49 | - | 3R | 350 | 5 | 14 | LM05GND | 532 | |
21.29 € | 1 | Available | 3 Days | Red | 20 | - | 2 | 40 | 1 | 9 | LM01RDD | 650 | |
16.93 € | 1 | Available | 3 Days | Red | 24 | Fixed-focus | 2 | 40 | 0.95 | 8 | LM01RDD-F | 650 |
Loading...
Basic information
| Product type | Laser module | RoHS-compliant | Yes | Emission characteristics | Dot |
|---|---|---|---|---|---|
| Max. temperature(°C) | 40 | Min. temperature(°C) | -10 | Operating voltage(V DC) | 3 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
