PLC digital input module

Catalog

Part number:

Still undefined. 83 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

Ambient temperature (max.)

(°C)

Colour

Inputs / outputs

IP rating

Manufacturer part #

Min. ambient temperature

(°C)

Mounting type

No. of digital inputs (max.)

Operating voltage

(V AC)

Operating voltage

(V DC)

Product size (height)

(mm)

Product size (width)

(mm)

Product size (length)

(mm)

Product type

Type (manufacturer type)

Type (misc.)

Weight

(g)

Minimum order quantity

+55	Light grey	Inputs: 16	IP20	750-1400	0	DIN 35 rail	16	-	24	64	12	100	PLC digital input module	750-1400	-	42.6	1 pieces
+55	Light grey	Inputs: 16	IP20	750-1402	0	DIN 35 rail	16	-	24	64	12	100	PLC digital input module	750-1402	-	41.5	1 pieces
+55	Light grey	Inputs: 16	IP20	750-1405	0	DIN 35 rail	16	-	24	64	12	100	PLC digital input module	750-1405	-	60	1 pieces
-	-	-	-	750-1405/040-000	-	-	-	-	-	-	-	-	PLC digital input module	750-1405/040-000	-	-	1 pieces
+55	Light grey	Inputs: 16	IP20	750-1407	0	DIN 35 rail	16	-	24	64	12	100	PLC digital input module	750-1407	-	60	1 pieces
+55	Light grey	Inputs: 8	IP20	750-1415	0	DIN 35 rail	8	-	24	64	12	100	PLC digital input module	750-1415	-	45	1 pieces
-	-	-	-	750-1415/040-000	-	-	-	-	-	-	-	-	PLC digital input module	750-1415/040-000	-	-	1 pieces
+55	Light grey	Inputs: 8	IP20	750-1416	0	DIN 35 rail	8	-	24	64	12	100	PLC digital input module	750-1416	-	45	1 pieces
-	-	-	-	750-1416/040-000	-	-	-	-	-	-	-	-	PLC digital input module	750-1416/040-000	-	-	1 pieces
+55	Light grey	Inputs: 8	IP20	750-1417	0	DIN 35 rail	8	-	24	64	12	100	PLC digital input module	750-1417	-	45	1 pieces
+55	Light grey	Inputs: 8	IP20	750-1418	0	DIN 35 rail	8	-	24	64	12	100	PLC digital input module	750-1418	-	45	1 pieces
+55	Light grey	Inputs: 4	IP20	750-1420	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-1420	-	50	1 pieces
+55	Light grey	Inputs: 4	IP20	750-1421	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-1421	-	50	1 pieces
+55	Light grey	Inputs: 4	IP20	750-1422	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-1422	-	50	1 pieces
+55	Light grey	Inputs: 4	IP20	750-1423	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-1423	-	50	1 pieces
+55	Light grey	-	IP20	750-1425	0	DIN 35 rail	8	-	-	64	12	100	PLC digital input module	750-1425	-	46.5	1 pieces
-	-	-	-	750-1515/040-000	-	-	-	-	-	-	-	-	PLC digital output module	750-1515/040-000	-	-	1 pieces
+55	Light grey	-	IP20	750-400	0	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	750-400	-	45.81	1 pieces
+60	Light grey	Inputs: 2	IP20	750-400/025-000	-20	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	750-400/025-000	-	49	1 pieces
+55	Light grey	-	IP20	750-401	0	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	750-401	-	45.841	1 pieces
+55	Light grey	-	IP20	750-402	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-402	-	46.849	1 pieces
+60	Light grey	Inputs: 4	IP20	750-402/025-000	-20	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-402/025-000	-	50	1 pieces
+55	Light grey	-	IP20	750-403	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-403	-	46.949	1 pieces
+55	Light grey	-	IP20	750-405	0	DIN 35 rail	2	230	-	64	12	100	PLC digital input module	750-405	-	47.793	1 pieces
+55	Light grey	-	IP20	750-406	0	DIN 35 rail	2	120	-	64	12	100	PLC digital input module	750-406	-	47.593	1 pieces
+55	Light grey	-	IP20	750-407	0	DIN 35 rail	2	-	220	64	12	100	PLC digital input module	750-407	-	47	1 pieces
-	-	-	-	750-407/040-000	-	-	-	-	-	-	-	-	PLC digital input module	750-407/040-000	-	-	1 pieces
+60	Light grey	-	IP20	750-408/025-000	-20	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-408/025-000	-	46.331	1 pieces
+55	Light grey	-	IP20	750-409	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-409	-	46.164	1 pieces
+55	Light grey	-	IP20	750-410	0	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	750-410	-	45.711	1 pieces
+55	Light grey	Inputs: 2	IP20	750-411	0	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	750-411	-	48.5	1 pieces
+55	Light grey	-	IP20	750-412	0	DIN 35 rail	2	-	48	64	12	100	PLC digital input module	750-412	-	46.025	1 pieces
+55	Light grey	Inputs: 4	IP20	750-414	0	DIN 35 rail	4	-	5	64	12	100	PLC digital input module	750-414	-	49.5	1 pieces
+55	Light grey	Inputs: 4	IP20	750-415	0	DIN 35 rail	4	-	24\|24	64	12	100	PLC digital input module	750-415	-	49.5	1 pieces
+55	Light grey	Inputs: 2	IP20	750-418	0	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	750-418	-	51	1 pieces
+55	Light grey	Inputs: 2	IP20	750-421	0	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	750-421	-	62	1 pieces
+55	Light grey	Inputs: 4	IP20	750-422	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-422	-	51	1 pieces
+55	Light grey	Inputs: 4	IP20	750-423	0	DIN 35 rail	4	-	24\|24	64	12	100	PLC digital input module	750-423	-	65	1 pieces
+55	Light grey	Inputs: 2	IP20	750-424	0	DIN 35 rail	-	-	24	64	12	100	PLC digital input module	750-424	-	36	1 pieces
+55	Light grey	-	IP20	750-425	0	DIN 35 rail	-	-	-	64	12	100	PLC digital input module	750-425	-	48.42	1 pieces
+55	Light grey	Inputs: 2	IP20	750-427	0	DIN 35 rail	2	-	110	64	12	100	PLC digital input module	750-427	-	47.214	1 pieces
-	-	-	-	750-427/040-000	-	-	-	-	-	-	-	-	PLC digital input module	750-427/040-000	-	-	1 pieces
+55	Light grey	Inputs: 4	IP20	750-428	0	DIN 35 rail	4	-	42\|42	64	12	100	PLC digital input module	750-428	-	49.5	1 pieces
-	-	-	-	750-429/040-001	-	-	-	-	-	-	-	-	PLC digital input module	750-429/040-001	-	-	1 pieces
+60	Light grey	Inputs: 8	IP20	750-430/025-000	-20	DIN 35 rail	8	-	24	64	12	100	PLC digital input module	750-430/025-000	-	48.5	1 pieces
-	-	-	-	750-430/040-000	-	-	-	-	-	-	-	-	PLC digital input module	750-430/040-000	-	-	1 pieces
+55	Light grey	Inputs: 8	IP20	750-431	0	DIN 35 rail	8	-	24	64	12	100	PLC digital input module	750-431	-	48.5	1 pieces
-	-	-	-	750-431/040-000	-	-	-	-	-	-	-	-	PLC digital input module	750-431/040-000	-	-	1 pieces
+55	Light grey	4 digital inputs	IP20	750-432	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-432	24 V/DC 3 ms (2 wires)	47.104	1 pieces
+55	Light grey	Inputs: 4	IP20	750-433	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	750-433	-	48.5	1 pieces
+55	Light grey	Inputs: 8	IP20	750-436	0	DIN 35 rail	8	-	24	64	12	100	PLC digital input module	750-436	-	48	1 pieces
+55	Light grey	Inputs: 8	IP20	750-437	0	DIN 35 rail	8	-	24	64	12	100	PLC digital input module	750-437	-	60	1 pieces
-	-	-	-	750-439	-	-	-	-	-	-	-	-	PLC digital input module	750-439	-	-	1 pieces
-	-	-	-	750-439/040-000	-	-	-	-	-	-	-	-	PLC digital input module	750-439/040-000	-	-	1 pieces
-	-	-	-	750-663/000-003	-	-	-	-	-	-	-	-	PLC digital input module	750-663/000-003	-	-	1 pieces
-	-	-	-	750-669/000-003	-	-	-	-	-	-	-	-	PLC digital input module	750-669/000-003	-	-	1 pieces
+55	Light grey	-	IP20	753-400	0	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	753-400	-	47.5	1 pieces
+55	Light grey	-	IP20	753-401	0	DIN 35 rail	2	-	24	64	12	100	PLC digital input module	753-401	-	41.5	1 pieces
+55	Light grey	Inputs: 4	IP20	753-402	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	753-402	-	42.5	1 pieces
+55	Light grey	Inputs: 4	IP20	753-403	0	DIN 35 rail	4	-	24	64	12	100	PLC digital input module	753-403	-	42.5	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

174.89 € ( 208.12 € )	7 working days
180.36 € ( 214.63 € )	7 working days
191.29 € ( 227.64 € )	3 working days
278.76 € ( 331.72 € )	7 working days
158.49 € ( 188.60 € )	7 working days
85.15 € ( 101.33 € )	3 working days
163.96 € ( 195.11 € )	7 working days
102.39 € ( 121.84 € )	7 working days
180.36 € ( 214.63 € )	7 working days
98.04 € ( 116.67 € )	36 working days
106.75 € ( 127.03 € )	7 working days
82.77 € ( 98.50 € )	7 working days
87.13 € ( 103.68 € )	7 working days
89.32 € ( 106.29 € )	7 working days
87.13 € ( 103.68 € )	8 working days
202.21 € ( 240.63 € )	7 working days
191.29 € ( 227.64 € )	7 working days
56.36 € ( 67.07 € )	3 working days
60.69 € ( 72.22 € )	7 working days
40.72 € ( 48.46 € )	37 working days
65.03 € ( 77.39 € )	3 working days
80.60 € ( 95.91 € )	7 working days
58.53 € ( 69.65 € )	7 working days
60.69 € ( 72.22 € )	7 working days
71.55 € ( 85.14 € )	7 working days
106.75 € ( 127.03 € )	7 working days
163.96 € ( 195.11 € )	36 working days
82.77 € ( 98.50 € )	7 working days
56.36 € ( 67.07 € )	7 working days
45.52 € ( 54.17 € )	7 working days
49.85 € ( 59.32 € )	7 working days
50.93 € ( 60.61 € )	7 working days
76.24 € ( 90.73 € )	7 working days
69.37 € ( 82.55 € )	7 working days
100.21 € ( 119.25 € )	7 working days
130.71 € ( 155.54 € )	7 working days
91.49 € ( 108.87 € )	7 working days
80.60 € ( 95.91 € )	7 working days
84.96 € ( 101.10 € )	7 working days
102.39 € ( 121.84 € )	7 working days
69.37 € ( 82.55 € )	7 working days
163.96 € ( 195.11 € )	7 working days
153.03 € ( 182.11 € )	7 working days
163.96 € ( 195.11 € )	8 working days
125.27 € ( 149.07 € )	7 working days
169.43 € ( 201.62 € )	7 working days
98.04 € ( 116.67 € )	7 working days
153.03 € ( 182.11 € )	7 working days
71.55 € ( 85.14 € )	3 working days
56.36 € ( 67.07 € )	7 working days
87.39 € ( 103.99 € )	7 working days
102.39 € ( 121.84 € )	7 working days
633.05 € ( 753.33 € )	36 working days
840.63 € ( 1,000.35 € )	7 working days
1,076.73 € ( 1,281.31 € )	7 working days
934.63 € ( 1,112.21 € )	7 working days
47.68 € ( 56.74 € )	7 working days
47.68 € ( 56.74 € )	7 working days
60.69 € ( 72.22 € )	7 working days
67.20 € ( 79.97 € )	7 working days
