Sensor / actuator cable SAC-5P
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
1669903
Basic information
| Halogen free | true | Rated voltage(V) | 24 | Cable length(m) | 5 |
|---|---|---|---|---|---|
| Type of cable | Multi-core | Screened | false | Number of poles | 5 |
| Permitted cable outer temperature during assembling/handling(°C) | -25|80 | Permitted cable outer temperature after assembling without vibration(°C) | -40|80 | Continuity resistor(mOhm) | 5000 |
| Material of contact surface | Ni/Au | Vulcanize | false | Material of cable sheath | Other |
| Degree of protection (IP) | - | Type of electrical connection, box-sided | Other | Type of electrical connection, field-sided | M12 |
| Positioning cable feed, box-sided | Other | Positioning cable feed, field-sided | Angled | With LED indication | true |
| Type of plug-in contact, field sided | Female (bus) | Material contact body | CuSn | Colour cable sheath | Black |
| Rated current In(A) | 4 | Type of plug-in contact, box-sided | - |
This page is Sensor / actuator cable SAC-5P, part number 1669903.
You can find the detail information about specifications and dimensions on part number 1669903.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
