Configure

Model
- -
- Other
Rated voltage(V)
- 500
- 1000
Number of poles
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
Width/grid dimension(mm)
- 5.2
- 8.2
- 10.4
- 15.4
- 16.4
- 20.6
- 24.6
- 25.7
- 30.9
- 31.5
- 32.8
- 35
- 36
- 38.5
- 41
- 41.2
- 42
- 45.5
- 46.3
- 49
- 49.2
- 51.5
- 52.5
- 56.6
- 57.4
- 61.8
- 65.6
- 66.9
- 72.1
- 73.8
- 77.2
- 82
Tackable
- -
- true
Total number of poles (without ground contact)
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- 13
- 14
- 15
Connectable conductor cross section solid-core(mm²)
Connectable conductor cross section fine-strand with cable end sleeve(mm²)
Connectable conductor cross section fine-strand without cable end sleeve(mm²)
Connectable conductor cross section multi-wired(mm²)
Connectable conductor cross section(mm²)
Rated current In(A)
- 17.5
- 24
- 41
Type
Est. shipping days
- All
- Within 7 working days
- Within 18 working days
- Within 21 working days
- Within 22 working days

COMBI receptacle, PPC

Catalog

Part number:

Still undefined. 35 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

Model

Rated voltage

(V)

Number of poles

Width/grid dimension

(mm)

Tackable

Total number of poles (without ground contact)

Connectable conductor cross section solid-core

(mm²)

Connectable conductor cross section fine-strand with cable end sleeve

(mm²)

Connectable conductor cross section fine-strand without cable end sleeve

(mm²)

Connectable conductor cross section multi-wired

(mm²)

Connectable conductor cross section

(mm²)

Rated current In

(A)

Minimum order quantity

Data sheet	-	500	1	5.2	-	1	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	250 pieces
Data sheet	-	500	2	10.4	-	2	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	150 pieces
Data sheet	-	500	3	15.4	-	3	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	100 pieces
Data sheet	-	500	4	20.6	-	4	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	100 pieces
Data sheet	-	500	5	25.7	-	5	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	100 pieces
Data sheet	-	500	6	30.9	-	6	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	50 pieces
Data sheet	-	500	7	36	-	7	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	50 pieces
Data sheet	-	500	8	41.2	-	8	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	50 pieces
Data sheet	-	500	9	46.3	-	9	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	50 pieces
Data sheet	-	500	10	51.5	-	10	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	50 pieces
Data sheet	-	500	11	56.6	-	11	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	30 pieces
Data sheet	-	500	12	61.8	-	12	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	30 pieces
Data sheet	-	500	13	66.9	-	13	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	30 pieces
Data sheet	-	500	14	72.1	-	14	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	30 pieces
Data sheet	-	500	15	77.2	-	15	0.14\|4	0.14\|2.5	0.14\|2.5	0.14\|2.5	0.14\|4	24	30 pieces
Data sheet	-	1000	1	8.2	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	150 pieces
Data sheet	-	1000	1	8.2	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	150 pieces
Data sheet	-	1000	1	8.2	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	150 pieces
Data sheet	-	1000	1	8.2	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	150 pieces
Data sheet	-	1000	2	16.4	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	50 pieces
Data sheet	-	1000	3	24.6	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	50 pieces
Data sheet	-	1000	4	32.8	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	50 pieces
Data sheet	-	1000	5	41	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	50 pieces
Data sheet	-	1000	6	49.2	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	25 pieces
Data sheet	-	1000	7	57.4	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	25 pieces
Data sheet	-	1000	8	65.6	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	25 pieces
Data sheet	-	1000	9	73.8	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	25 pieces
Data sheet	-	1000	10	82	true	2	0.5\|10	0.5\|6	0.5\|6	0.5\|6	0.5\|10	41	25 pieces
Data sheet	Other	500	9	31.5	true	1	0.14\|1.5	0.14\|1	0.14\|1.5	0.14\|1.5	0.14\|1.5	17.5	50 pieces
Data sheet	Other	500	10	35	true	1	0.14\|1.5	0.14\|1	0.14\|1.5	0.14\|1.5	0.14\|1.5	17.5	50 pieces
Data sheet	Other	500	11	38.5	true	1	0.14\|1.5	0.14\|1	0.14\|1.5	0.14\|1.5	0.14\|1.5	17.5	30 pieces
Data sheet	Other	500	12	42	true	1	0.14\|1.5	0.14\|1	0.14\|1.5	0.14\|1.5	0.14\|1.5	17.5	30 pieces
Data sheet	Other	500	13	45.5	true	1	0.14\|1.5	0.14\|1	0.14\|1.5	0.14\|1.5	0.14\|1.5	17.5	30 pieces
Data sheet	Other	500	14	49	true	1	0.14\|1.5	0.14\|1	0.14\|1.5	0.14\|1.5	0.14\|1.5	17.5	30 pieces
Data sheet	Other	500	15	52.5	true	1	0.14\|1.5	0.14\|1	0.14\|1.5	0.14\|1.5	0.14\|1.5	17.5	30 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

0.81 € ( 0.96 € )	21 working days
1.78 € ( 2.12 € )	7 working days
2.29 € ( 2.73 € )	7 working days
2.80 € ( 3.33 € )	7 working days
3.32 € ( 3.95 € )	21 working days
3.82 € ( 4.55 € )	7 working days
4.34 € ( 5.16 € )	21 working days
4.85 € ( 5.77 € )	7 working days
5.37 € ( 6.39 € )	21 working days
5.88 € ( 7.00 € )	7 working days
6.40 € ( 7.62 € )	21 working days
6.90 € ( 8.21 € )	21 working days
7.41 € ( 8.82 € )	21 working days
7.94 € ( 9.45 € )	21 working days
8.45 € ( 10.06 € )	21 working days
1.74 € ( 2.07 € )	7 working days
1.74 € ( 2.07 € )	7 working days
1.74 € ( 2.07 € )	22 working days
1.74 € ( 2.07 € )	22 working days
3.85 € ( 4.58 € )	22 working days
4.96 € ( 5.90 € )	22 working days
6.08 € ( 7.24 € )	22 working days
7.19 € ( 8.56 € )	22 working days
8.31 € ( 9.89 € )	22 working days
9.45 € ( 11.25 € )	22 working days
10.57 € ( 12.58 € )	22 working days
11.68 € ( 13.90 € )	22 working days
12.85 € ( 15.29 € )	22 working days
5.16 € ( 6.14 € )	18 working days
5.68 € ( 6.76 € )	7 working days
6.16 € ( 7.33 € )	18 working days
6.66 € ( 7.93 € )	7 working days
7.15 € ( 8.51 € )	18 working days
7.65 € ( 9.10 € )	18 working days
8.13 € ( 9.67 € )	18 working days
