Sensor / actuator box, SACB
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1060994 |
| 1097569 |
| 1097602 |
| 1097612 |
| 1097629 |
| 1097635 |
| 1401199 |
| 1405737 |
| 1405738 |
| 1405739 |
| 1405740 |
| 1412058 |
| 1412059 |
| 1412060 |
| 1437245 |
| 1516742 |
| 1516849 |
| 1516865 |
| 1516878 |
| 1516975 |
| 1692747 |
| 1692776 |
| 1692802 |
| 1692828 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Width (mm) | Height (mm) | Colour housing | Rated voltage (V) | Material housing | Operation temperature (°C) | With potential separation | Operating voltage (V) | Material of contact surface | Max. total current (A) | Degree of protection (IP) | With LED indication | Pollution degree | Connection for NPN-sensors | Number of channels per connector slot | Number of sensor-/actuator-slots | Length of the preassembled cable (m) | Cable outer diameter for cable gland (mm) | Number of poles sensor/actuator slots | Material insulation body | Material contact body | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
518.28 € | 25 | Quote | - | - | - | 24 | - | -|- | false | 30|30 | Gold | 12 | - | true | - | false | 2 | 8 | 20 | -|- | 5 | PBT | - | |||
59.72 € | 4 | 40 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | 2 | false | 2 | 4 | 1.5 | -|- | 5 | PA | - | |||
128.94 € | 2 | 40 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | 2 | false | 2 | 4 | 15 | -|- | 5 | PA | - | |||
88.07 € | 3 | 40 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | - | false | 2 | 8 | 1.5 | -|- | 5 | PA | - | |||
97.47 € | 2 | 40 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | 2 | false | 2 | 8 | 3 | -|- | 5 | PA | - | |||
172.97 € | 2 | 7 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | 2 | false | 2 | 8 | 15 | -|- | 5 | PA | - | |||
201.70 € | 1 | 35 Days | 58 | 26 | Black | 24 | Plastic | -30|90 | false | 30|30 | Gold | 12 | IP65 | true | - | false | 2 | 8 | 5 | -|- | 5 | PA | Other copper alloys | |||
84.22 € | 3 | 7 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | 2 | true | 1 | 8 | 5 | -|- | 4 | PA | Other copper alloys | |||
107.82 € | 2 | 40 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | 2 | true | 1 | 8 | 10 | -|- | 4 | PA | Other copper alloys | |||
114.15 € | 2 | 40 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | 2 | true | 2 | 8 | 5 | -|- | 5 | PA | Other copper alloys | |||
145.41 € | 2 | 40 Days | 54 | 23 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 12 | IP65 | true | 2 | true | 2 | 8 | 10 | -|- | 5 | PA | Other copper alloys | |||
79.20 € | 3 | 7 Days | 54 | 43 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 8 | IP65 | true | 2 | false | 2 | 4 | 0 | 7|12 | 5 | PA | Other copper alloys | |||
98.31 € | 2 | 36 Days | 54 | 43 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 8 | IP65 | true | 2 | false | 2 | 6 | 0 | 7|12 | 5 | PA | Other copper alloys | |||
114.58 € | 2 | 7 Days | 54 | 43 | Other | 24 | Plastic | -25|80 | false | 30|30 | Gold | 8 | IP65 | true | 2 | false | 2 | 8 | 0 | 7|12 | 5 | PA | Other copper alloys | |||
183.00 € | 1 | 35 Days | 58 | 28 | Green | 24 | Plastic | -30|80 | false | 30|30 | Gold | 12 | IP54 | true | - | false | 1 | 8 | 1.5 | -|- | 4 | PA | Other copper alloys | |||
79.15 € | 3 | 7 Days | 58 | 26 | Green | 24 | Plastic | -30|80 | true | 30|30 | Gold | 10 | IP65 | true | - | false | 1 | 6 | 0 | -|- | 4 | PA | Other copper alloys | |||
65.47 € | 3 | 35 Days | 58 | 45 | Green | 120 | Plastic | -30|80 | true | 135|135 | Gold | 10 | IP65 | false | - | true | 1 | 4 | 0 | 7|12 | 4 | PA | Other copper alloys | |||
83.42 € | 3 | 35 Days | 58 | 45 | Green | 120 | Plastic | -30|80 | true | 135|135 | Gold | 10 | IP65 | false | - | true | 1 | 6 | 0 | 7|12 | 4 | PA | Other copper alloys | |||
94.30 € | 2 | 7 Days | 58 | 45 | Green | 120 | Plastic | -30|80 | true | 135|135 | Gold | 10 | IP65 | false | - | true | 2 | 6 | 0 | 7|12 | 5 | PA | Other copper alloys | |||
102.59 € | 2 | 35 Days | 58 | 26 | Green | 120 | Plastic | -30|90 | false | 135|135 | Gold | 12 | IP65 | false | - | true | 1 | 4 | 10 | 8.7|8.7 | 4 | PA | Other copper alloys | |||
115.10 € | 2 | 7 Days | 54 | 34 | Green | 120 | Plastic | -20|75 | false | 135|135 | Nickel | 12 | IP65 | false | - | true | 2 | 4 | 0 | -|- | 5 | PA | - | |||
119.75 € | 2 | 35 Days | 54 | 34 | Green | 120 | Plastic | -20|75 | false | 135|135 | Nickel | 12 | IP65 | false | - | true | 1 | 8 | 0 | -|- | 4 | PA | - | |||
109.72 € | 2 | 7 Days | 54 | 26 | Green | 120 | Plastic | -20|75 | false | 135|135 | Nickel | 12 | IP65 | false | - | true | 2 | 4 | 0 | -|- | 5 | PA | - | |||
129.57 € | 2 | 7 Days | 54 | 26 | Green | 120 | Plastic | -20|75 | false | 135|135 | Nickel | 12 | IP65 | false | - | true | 2 | 6 | 0 | -|- | 5 | PA | - |
Loading...
Basic information
| Depth(mm) | - | Explosion safety category for gas | Other | Explosion safety category for dust | Other |
|---|---|---|---|---|---|
| Max. current carrying capacity per I/O signal(A) | 2 | Max. current carrying capacity per socket(A) | 4 | Type of branches for sensor-/actuator cables | M12 |
| Thread sleeves sensor/actuator slots | M12 | Cable length configurable | false | Diameter contact female(mm) | - |
| Fix cable version suitable for cable guide chain | true | Type of connector for trunk line | - | Connectable conductor cross section(mm²) | -|- |
| Degree of protection (NEMA) | - |
Configure
Basic Attributes
-
Width(mm)
-
Height(mm)
-
Colour housing
-
Rated voltage(V)
-
Material housing
-
Operation temperature(°C)
-
With potential separation
-
Operating voltage(V)
-
Material of contact surface
-
Max. total current(A)
-
Degree of protection (IP)
-
With LED indication
-
Pollution degree
-
Connection for NPN-sensors
-
Number of channels per connector slot
-
Number of sensor-/actuator-slots
-
Length of the preassembled cable(m)
-
Cable outer diameter for cable gland(mm)
-
Number of poles sensor/actuator slots
-
Material insulation body
-
Material contact body
-
Type
Filter by standard shipping days
-
- All
- 7 Days or Less
- 35 Days or Less
- 36 Days or Less
- 40 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
