Housing, Box mounting base, HC-STA-10
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1082578 |
| 1082579 |
| 1082580 |
| 1082582 |
| 1082583 |
| 1082585 |
| 1082598 |
| 1082599 |
| 1083164 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Width (mm) | Height (mm) | With hinged lid | Locking mechanism | |
|---|---|---|---|---|---|---|---|---|---|
30.80 € | 6 | 98 Days | 70.65 | 97.92 | false | Single locking lever | |||
30.80 € | 6 | 7 Days | 70.65 | 99.3 | false | Single locking lever | |||
30.80 € | 6 | 98 Days | 70.65 | 100.62 | false | Single locking lever | |||
38.30 € | 5 | 7 Days | 106.96 | 97.92 | true | Single locking lever | |||
38.30 € | 5 | 7 Days | 106.96 | 99.3 | true | Single locking lever | |||
38.30 € | 5 | 7 Days | 106.96 | 100.62 | true | Single locking lever | |||
30.90 € | 6 | 98 Days | 57 | 104.14 | false | Double locking levers | |||
30.90 € | 6 | 98 Days | 57 | 104.83 | false | Double locking levers | |||
30.90 € | 6 | 98 Days | 57 | 106.16 | false | Double locking levers |
Loading...
Basic information
| UV resistant | false | Depth(mm) | - | Colour housing | - |
|---|---|---|---|---|---|
| Number of conduit inlets | - | With cable screw gland | false | EMC-version | true |
| Corrosion resistant | - | Material housing | Other | Coating housing | Uncoated |
| Operation temperature(°C) | -40|125 | Inflammability class of insulation material acc. with UL94 | Other | Impact strength | - |
| With distance piece | - | Number of openings | - | With sealing | - |
| Type of housing | Socket case | Degree of protection (IP), mounted | IP66 | Material adapter plate | - |
| Position cable feed | Sideways | Position of the shackle | Cover | Mounting method of the cable gland | - |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
