PHOENIX CONTACT

Feed-through terminal block, UK

Feed-through terminal block, UK

Part number:

Still undefined. 7 possible part numbers found.
    Quantity:

    Part number list

    Number of items
  • 1
    • Part number
    1002940
    3000562
    3000569
    3000570
    3000571
    3048154
    3048441
    Related

    Colour

    Rated voltage

    (V)

    Length

    (mm)

    Width/grid dimension

    (mm)

    Height at lowest possible mounting height

    (mm)

    Closing plate required

    Type of electrical connection 1

    Type of electrical connection 2

    Number of clamp positions per level

    Connectable conductor cross section solid-core

    (mm²)

    Connectable conductor cross section fine-strand with cable end sleeve

    (mm²)

    Connectable conductor cross section fine-strand without cable end sleeve

    (mm²)

    Connectable conductor cross section multi-wired

    (mm²)

    Connection position

    Rated current In

    (A)

    Explosion-tested version 'Ex e'

    		Minimum order quantity

    Data sheet

    Orange
    800
    87
    6.2
    36.5
    true
    Spring clamp connection
    Spring clamp connection
    4
    0.08|6
    0.14|4
    0.08|4
    0.08|4
    -
    32
    true
    100 pieces

    Data sheet

    Grey
    800
    58
    8.2
    40.3
    true
    Screw connection
    Screw connection
    2
    0.2|6
    0.25|2.5
    0.2|4
    0.2|1.5
    -
    32
    -
    100 pieces

    Data sheet

    Yellow
    800
    42.5
    12.2
    54
    true
    Screw connection
    Screw connection
    2
    2.5|25
    1.5|16
    4|16
    1.5|6
    -
    76
    true
    50 pieces

    Data sheet

    Green
    800
    42.5
    12.2
    54
    true
    Screw connection
    Screw connection
    2
    2.5|25
    1.5|16
    4|16
    1.5|6
    -
    76
    true
    50 pieces

    Data sheet

    Red
    800
    42.5
    12.2
    54
    true
    Screw connection
    Screw connection
    2
    2.5|25
    1.5|16
    4|16
    1.5|6
    -
    76
    true
    50 pieces

    Data sheet

    Other
    1000
    50
    15.1
    62
    false
    Screw connection
    Screw connection
    2
    0.75|50
    0.75|35
    0.75|35
    0.75|16
    -
    150
    true
    50 pieces

    Data sheet

    Grey
    800
    42.5
    6.2
    47
    true
    Screw connection
    Screw connection
    2
    0.2|6
    0.25|2.5
    0.2|4
    0.2|1.5
    Sideways
    32
    false
    100 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    2.48 €
    ( 2.95 € )
    22 working days
    2.40 €
    ( 2.86 € )
    67 working days
    4.58 €
    ( 5.45 € )
    49 working days
    4.58 €
    ( 5.45 € )
    44 working days
    4.33 €
    ( 5.15 € )
    49 working days
    13.21 €
    ( 15.72 € )
    23 working days
    2.13 €
    ( 2.53 € )
    7 working days
  • 1
