Printed-circuit board connector, PCB connector, PTSM
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1709435 |
| 1709442 |
| 1709457 |
| 1709459 |
| 1709460 |
| 1709462 |
| 1709463 |
| 1709464 |
| 1709465 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Colour housing | Contact type | Operation temperature (°C) | |
|---|---|---|---|---|---|---|---|
1.33 € | 250 | 28 Days | Black | Pin | -40|-40 | ||
1.27 € | 250 | 36 Days | Black | Bus | -40|100 | ||
1.27 € | 250 | 7 Days | White | Bus | -40|100 | ||
1.80 € | 250 | 28 Days | White | Bus | -40|100 | ||
2.34 € | 250 | 7 Days | White | Bus | -40|100 | ||
2.88 € | 100 | 28 Days | White | Bus | -40|100 | ||
3.42 € | 100 | 28 Days | White | Bus | -40|100 | ||
3.95 € | 100 | 28 Days | White | Bus | -40|100 | ||
4.49 € | 100 | 28 Days | White | Bus | -40|100 |
Loading...
Basic information
| Type of connection | Printed circuit board to cable | Rated voltage(V) | 160 | Number of poles | - |
|---|---|---|---|---|---|
| Material housing | Other | Coating housing | - | Inflammability class of insulation material acc. with UL94 | V0 |
| Rated surge voltage(kV) | 2.5 | Type of electric connection | Other | Material of contact surface | Tin |
| Over voltage category | III | Pollution degree | 2 | Connectable cable type | Tubular cable |
| Modular spacing connections(mm) | 2.5 | Number of plug-in contact rows | 1 | Modular spacing contacts(mm) | 2.5 |
| Connectable conductor cross section solid-core(mm²) | 0.14|0.5 | Connectable conductor cross section fine-strand with cable end sleeve(mm²) | 0.25|0.5 | Connectable conductor cross section fine-strand without cable end sleeve(mm²) | 0.2|0.5 |
| Connectable conductor cross section multi-wired(mm²) | 0.2|0.5 | Degree of protection (IP), mounted | Other | With protective conductor | - |
| Material insulation body | Other | Material contact | Copper | Angle contact/conductor connection | 180° (horizontal) |
| Rated current In(A) | 6 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
