Printed-circuit board connector, PCB connector, GMVSTBR
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1737770 |
| 1737783 |
| 1737796 |
| 1737806 |
| 1774454 |
| 1809898 |
| 1809908 |
| 1809911 |
| 1809924 |
| 1809937 |
| 1809940 |
| 1809953 |
| 1809966 |
| 1809979 |
| 1809982 |
| 1809995 |
| 1847932 |
| 1847958 |
| 1847961 |
| 1847974 |
| 1999932 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Rated voltage (V) | Operation temperature (°C) | Modular spacing connections (mm) | Modular spacing contacts (mm) | Degree of protection (IP), mounted | |
|---|---|---|---|---|---|---|---|---|---|
10.28 € | 50 | 43 Days | 630 | -40|100 | 7.5 | 7.5 | Other | ||
11.42 € | 50 | 43 Days | 630 | -40|100 | 7.5 | 7.5 | Other | ||
12.56 € | 50 | 7 Days | 630 | -40|100 | 7.5 | 7.5 | Other | ||
13.70 € | 50 | 43 Days | 630 | -40|100 | 7.5 | 7.5 | Other | ||
3.43 € | 100 | 7 Days | 630 | -40|100 | 7.62 | 7.62 | Other | ||
2.87 € | 100 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
4.24 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
5.61 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
6.98 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
8.35 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
9.72 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
11.09 € | 50 | 39 Days | 352 | -|- | 7.62 | 7.62 | - | ||
12.46 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
13.83 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
15.19 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
16.56 € | 50 | 43 Days | 352 | -|- | 7.62 | 7.62 | - | ||
8.12 € | 50 | 46 Days | 630 | -40|100 | 7.62 | 7.62 | Other | ||
10.40 € | 50 | 43 Days | 630 | -40|100 | 7.62 | 7.62 | Other | ||
11.54 € | 50 | 43 Days | 630 | -40|100 | 7.62 | 7.62 | Other | ||
12.68 € | 50 | 43 Days | 630 | -40|100 | 7.62 | 7.62 | Other | ||
9.46 € | 50 | 43 Days | 630 | -40|100 | 7.62 | 7.62 | - |
Loading...
Basic information
| Type of connection | Printed circuit board to cable | Colour housing | Green | Number of poles | - |
|---|---|---|---|---|---|
| Contact type | Bus | Material housing | Other | Coating housing | - |
| Inflammability class of insulation material acc. with UL94 | V0 | Rated surge voltage(kV) | 6 | Type of electric connection | Screw connection |
| Material of contact surface | Tin | Over voltage category | III | Pollution degree | 2 |
| Connectable cable type | Tubular cable | Number of plug-in contact rows | 1 | Connectable conductor cross section solid-core(mm²) | 0.2|2.5 |
| Connectable conductor cross section fine-strand with cable end sleeve(mm²) | 0.25|2.5 | Connectable conductor cross section fine-strand without cable end sleeve(mm²) | 0.2|2.5 | Connectable conductor cross section multi-wired(mm²) | 0.2|1 |
| With protective conductor | - | Material insulation body | Other | Material contact | Copper |
| Angle contact/conductor connection | 90° (upwards vertical) | Rated current In(A) | 12 |
