Macro Pallet Holder 70 x 70
Click on this image to zoom in.
Click on this image to zoom in.
70 x 70 x 12.5 mm precision cast holder made of SUS. Used for pallets for workpieces and dedicated jigs
[Features]
· Precision cast product with 8 mounting screw holes included. Hardened
[Features]
· Precision cast product with 8 mounting screw holes included. Hardened
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
3R-601.7-P
Basic information
| Product Type | Other Jigs | Fixed Indexed Position | 4×90° | Dimensions 1 | 70x70x12.5mm |
|---|---|---|---|---|---|
| Mounting Screw Hole | 8 pcs. | Surface Treatment | Z-Axis and Mounting Surface Grinding Completed, Anti-Rust Processed | Note | Automatic Exchange Supported |
| Weight | 3kg | Remarks | Before clamping the chuck, please attach it to a workbench or jig. |
This page is Macro Pallet Holder 70 x 70, part number 3R-601.7-P.
You can find the detail information about specifications and dimensions on part number 3R-601.7-P.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
