Angle Grinder NAG-70S
- Volume Discount
[Specifications]
· Applicable for Metal Grinding and Plane Polishing
· Material: Cast Iron, Aluminum Alloy, Chrome Molybdenum Steel
· Operating Air Pressure: 0.6 MPa
· Tip tool: Grindstone
· No-load rotations (rpm): 7,600
· Air Consumption Amount ([[m3]]/min): 1.10
· Hose Inlet: Rc3/8
· Exhaust: Side
· Overall length (mm): 238
· No-load rotations (min^[[-1]]): 7,600
· Applicable Grindstone Dimensions Outer Diameter x Thickness x Inner Diameter (mm): 180 x 6 x 22
· Applicable for Metal Grinding and Plane Polishing
· Material: Cast Iron, Aluminum Alloy, Chrome Molybdenum Steel
· Operating Air Pressure: 0.6 MPa
· Tip tool: Grindstone
· No-load rotations (rpm): 7,600
· Air Consumption Amount ([[m3]]/min): 1.10
· Hose Inlet: Rc3/8
· Exhaust: Side
· Overall length (mm): 238
· No-load rotations (min^[[-1]]): 7,600
· Applicable Grindstone Dimensions Outer Diameter x Thickness x Inner Diameter (mm): 180 x 6 x 22
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
10026
Basic information
| Grindstone Dimensions Capacity(mm) | 180×6×22 | Number of load-free rotations(min-1) | 7600 | Overall Length(mm) | 238 |
|---|---|---|---|---|---|
| Full height(mm) | 109 | Weight(g) | 2800 | Hose B Diameter Fixing Screw(Rc) | 3/8 |
| Hose I.D.(mm) | 12.7 | Air Consumption Amount(m3/min) | 1.1 |
This page is Angle Grinder NAG-70S, part number 10026.
You can find the detail information about specifications and dimensions on part number 10026.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
